Omron NB7W-TW01B Human Machine Interfaces
Omron NB7W-TW01B is a 7.0-inch Human Machine Interface featuring an 800 × 480 TFT LCD with 65,536 colors. The touchscreen supports machine status, operating values, alarms, and graphical controls within a dedicated operator panel. Backlight lifetime is specified at 50,000 hours, while power consumption is 7 W. Panel dimensions are 148 × 202 × 46 mm. Within the NB Series, the NB7W-TW01B-V1 provides a 7.0-inch touchscreen configuration for machine monitoring and operator interaction. For related machine-interface requirements, explore 7-inch touchscreen HMIs available across Omron automation products.
| Brand | Omron |
| Product Type | Human Machine Interface |
| Model Number | NB7W-TW01B |
Omron NB7W-TW01B Human Machine Interfaces - Technical Specifications:
| Specification | Value |
|---|---|
| Screen Size | 7.0 inches |
| Resolution | 800x480 |
| Colors | 65,536 colors |
| Type of display | TFT LCD |
| Backlight Lifetime | 50,000 hours |
| Dimensions in mm (H × W × D) | 148 × 202 × 46 |
| Weight | 715 g max |
| Power Consumption | 7 W |
The Omron NB7W-TW01B Human Machine Interface uses a 7.0-inch TFT LCD with 800 × 480 resolution and 65,536 colors. Its touchscreen supports machine status, operating values, alarms, and graphical control functions within a dedicated operator interface. Backlight lifetime is specified at 50,000 hours, while power consumption is 7 W. Panel dimensions are 148 × 202 × 46 mm. The 7.0-inch display provides a defined viewing area for machine visualization and direct touchscreen interaction.
The NB7W-TW01B-V1 should be evaluated by its 7.0-inch display, 800 × 480 resolution, 65,536-color TFT LCD, panel dimensions, and 7 W power requirement. These specifications help determine whether the panel matches the required operator-viewing area and available machine space. A related NB Series model is available with a 5.6-inch TFT LCD and 320 × 234 resolution for installations requiring a smaller screen format. For the related model, see Omron NB5Q-TW01B.
