Omron NB5Q-TW01B Human Machine Interfaces
Omron NB5Q-TW01B is a 5.6-inch Human Machine Interface with a 320 × 234 TFT LCD and 65,536-color display. The touchscreen supports presentation of machine conditions, operating values, alarms, and graphical controls through a compact operator interface. Backlight lifetime is specified at 50,000 hours, while power consumption is 6 W. Panel dimensions are 142 × 184 × 46 mm. Within the NB Series, the NB5Q-TW01B-V1 provides a 5.6-inch touchscreen configuration for machine visualization. For related operator-panel requirements, browse touchscreen HMI models available through Omron automation equipment.
| Brand | Omron |
| Product Type | Human Machine Interface |
| Model Number | NB5Q-TW01B |
Omron NB5Q-TW01B Human Machine Interfaces - Technical Specifications:
| Specification | Value |
|---|---|
| Screen Size | 5.6 inches |
| Resolution | 320x234 |
| Colors | 65,536 colors |
| Type of display | TFT LCD |
| Backlight Lifetime | 50,000 hours |
| Dimensions in mm (H × W × D) | 142 × 184 × 46 |
| Weight | 627 g max |
| Power Consumption | 6 W |
The Omron NB5Q-TW01B Human Machine Interface provides a 5.6-inch TFT LCD with 320 × 234 resolution and 65,536 colors. Its touchscreen supports machine conditions, operating values, alarms, and graphical controls within a compact operator panel. Backlight lifetime is specified at 50,000 hours, while power consumption is 6 W. Panel dimensions are 142 × 184 × 46 mm. The 5.6-inch display provides a defined graphical workspace for machine monitoring and operator interaction.
The NB5Q-TW01B-V1 should be evaluated using its 5.6-inch display size, 320 × 234 resolution, 65,536-color TFT LCD, panel dimensions, and 6 W power requirement. These specifications establish the required installation area and interface size for the machine panel. A related NB Series configuration is available with a 7.0-inch TFT LCD and 800 × 480 resolution when a larger screen format is required. For the related model, see Omron NB7W-TW01B.
