Omron MY3N DC24 Relay

Name: Omron MY3N DC24
Brand: Omron
SKU: MY3N DC24
Rating: 4.9 (4 reviews)

The Omron MY3N DC24 Relay delivers reliable switching performance with a Closed type (cover) protective housing, Plug-in terminal structure compatible with a Socket for secure mounting. It provides a 3PDT contact form with a Single contact method and uses Ag contacts to ensure long electrical life. Supporting a max contact current of AC: 5 A DC: 5 A loads. Built with a 650 Ω coil resistance, it ensures dependable response with an 80% max. operate voltage and 10 % min. release voltage. Supporting 250 VAC 125 VDC maximum contact voltage. Manufactured by Omron, listed under Omron Relay solutions, this model belongs to theMY Series.

Datasheet

Brand	Omron
Product Type	Relay
Model Number	MY3N DC24

Omron MY3N DC24 Relay - Technical Specifications

Specification	Value
Terminal structure	Plug-in terminal
Degree of protection	Closed type (cover)
Coil resistance	650 Ω
Operate voltage (Set voltage)	80% max.
Release voltage (Reset voltage)	10 % min.
Contact rated load	220 VAC 5 A (Resistive load) 220 VAC 2 A (Inductive load (cosφ = 0.4)) 24 VDC 5 A (Resistive load) 24 VDC 2 A (Inductive load (L/R = 7 ms))
Max. contact voltage	250 VAC 125 VDC
Max. Contact Current	AC: 5 A DC: 5 A
Maximum switching power	1100 VA (Resistive load) 440 VA (Inductive load (cosφ = 0.4)) 120 W (Resistive load) 48 W (Inductive load (L/R = 7 ms))
Contact method	Single
Contact form	3PDT
Contact resistance	50 mΩ max. (Voltage drop method with 5 VDC 1 A)
Operating time	20 ms max. (With rated operating power applied, not including contact bounce)
Reset time	20 ms max. (With rated operating power applied, not including contact bounce)
Maximum operating frequency	Mechanical: 18000 time/hour Rated load: 1800 time/hour
Ambient temperature (Operating)	-55 to 60 ℃ (with no freezing or condensation)
Ambient humidity (Operating)	5 to 85%
Mounting method	Socket
Coil ratings	24 VDC 36.9 mA
Contact material	Ag
Power consumption	Approx. 0.9 W
Weight	Approx. 35 g
