Omron MY2IN 220/240VAC (S) Relay
The Omron MY2IN 220/240VAC (S) Relay provides dependable performance with a DPDT contact configuration, socket mounting, and a 230 VAC rated coil offering stable operation at 5.3 mA. It features a coil resistance of 18.79 kΞ©, 1.2 VA power consumption, and fast response times with 20 ms max operating and reset time. Designed for durability, it supports a 10 A resistive load for both AC and DC ratings, with a maximum switching voltage of 250 VAC / 125 VDC. Built with Au-cladded + Ag alloy contacts and an LED indicator, it ensures high-reliability operation in industrial control environments. Manufactured by Omron and listed under Omron Relay solutions, this model is listed under the Omron MY Series.
| Brand | Omron |
| Product Type | Relay |
| Model Number | MY2IN 220/240VAC (S) |
Omron MY2IN 220/240VAC (S) Relay - Technical Specifications
| Specification | Value |
|---|---|
| Coil resistance | 18.79kΞ© |
| Contact resistance | 50 mΞ© max. (Voltage drop method with 5 VDC 1 A) |
| Operating time | 20 ms max. (With rated operating power applied, not including contact bounce) |
| Reset time | 20 ms max. (With rated operating power applied, not including contact bounce) |
| Maximum operating frequency | Mechanical: 18000 time/hour Rated load: 1800 time/hour |
| Ambient temperature (Operating) | -55 to 70 β (with no freezing or condensation) |
| Ambient humidity (Operating) | 5 to 85 % |
| Contacts configuration | DPDT |
| Coil power consumption | 1.2VA |
| Mounting | socket |
| Contact material | Au cladding + Ag alloy |
| Rated coil voltage | 230V AC |
| AC contacts rating @R (at resistive load) | 10A / 220V AC |
| DC contacts rating @R (at resistive load) | 10A / 24V DC |
| Maximum switching voltage | Max. 125V DC, max. 250V AC |
| Body dimensions | 27.94Γ21.59Γ36.06mm |
| Coil current | 5.3mA |
| Leads | Connectors 2, 5Γ0, 5mm |
| Indication | LED |
| Weight | Approx. 35 g |
