Omron J7KC-12-01 DC24 Relay
The Omron J7KC-12-01 DC24 Relay offers reliable operation with a magnetic contactor design, 24 VDC coil rating, and an SPST-1NC auxiliary contact for safe control performance. It features a double-break contact form using single main contacts and bifurcated auxiliary contacts, ensuring high contact reliability and long service life. Built with Ag alloy contact material and integrated surge absorption, it provides stable switching for motor control applications up to 2.2 kW at 240 VAC. Compact and designed for Push-In Plus wiring, it supports fast installation and safety-rated operation. Manufactured by Omron and listed under Omron Relay solutions, this model belongs to the J7KC Series.
| Brand | Omron |
| Product Type | Relay |
| Model Number | J7KC-12-01 DC24 |
Omron J7KC-12-01 DC24 Relay - Technical Specifications
| Specification | Value |
|---|---|
| Terminal structure | Magnetic contactor |
| Coil ratings | 24 VDC |
| Auxiliary contact | SPST-1NC |
| Contact form | Double break form (main circuit: single contacts, auxiliary circuit: bifurcated contacts) |
| Contact material | Ag alloy |
| Contact resistance | 50 mΞ© max. (6 VDC, 1 mA, voltage drop method) |
| Ambient temperature (Operating) | β40 to +65Β°C (no condensation or icing) |
| Ambient humidity (Operating) | 45% to 85% RH (no condensation or icing) |
| Weight | 160 g |
The Omron J7KC-12-01 DC24 is engineered with a magnetic contactor design that includes a double break contact form, providing robust performance for both the main and auxiliary circuits. The main circuit uses single contacts, while the auxiliary circuit incorporates bifurcated contacts for superior reliability. This configuration ensures efficient operation in complex industrial environments where durability is essential.
With a 24 VDC coil rating and a contact resistance of just 50 mΞ© max, the J7KC-12-01 DC24 offers excellent conductivity and minimal energy loss, making it an ideal choice for industrial control applications. This relay guarantees fast switching actions, with a maximum operating time of 50 ms for both ON and OFF states. It also features a reset time of 50 ms, ensuring seamless transitions between operational cycles, enhancing overall system efficiency.
Designed to operate in harsh conditions, the J7KC-12-01 DC24 functions within a temperature range of β40 to +65Β°C and can withstand ambient humidity levels ranging from 45% to 85% RH. Its durable build, featuring Ag alloy contact material, ensures reliable performance in a variety of industrial settings. The unit weighs approximately 160 g and is designed for socket mounting, offering easy integration into existing systems. For more details, visit the official Omron J7KC-12-01 DC24 product page.
