Omron G9SX-GS226-T15-RC Safety Relay Unit
The Omron G9SX-GS226-T15-RC Safety Relay Unit provides long-duration 150-second OFF-delay control, ensuring extended machine safety management. Powered by 24 VDC with a β15% to +10% tolerance, it supports a 30 ms operating time and fast 10 ms response for effective circuit shutdown. Its rugged construction offers resistance to vibration, shock, and environmental conditions ranging from β10 to 55Β°C with up to 85% RH. Manufactured by Omron and classified under Omron Relay, this unit is part of the G9SX Series.
| Brand | Omron |
| Product Type | Safety Relay Unit |
| Model Number | G9SX-GS226-T15-RC |
Omron G9SX-GS226-T15-RC Safety Relay Unit - Technical Specifications
| Specification | Value |
|---|---|
| OFF-delay time | 150 s |
| Rated voltage | 24 VDC |
| Operating voltage range | -15% to +10% of rated supply voltage |
| Power consumption | 2 W max |
| Operating time | 30 ms max |
| Response time | 10 ms max |
| Vibration resistance | Frequency: 10 to 55 to 10 Hz, 0.375-mm single amplitude (0.75-mm double amplitude) |
| Shock resistance | Destruction 300 m/s2 Malfunction 100 m/s2 |
| Ambient operating temperature | β10 to 55Β°C (with no icing or condensation) |
| Ambient operating humidity | 25% to 85% |
| Terminal tightening torque | 0.5 NΒ·m |
| Weight | Approx. 165 g |
The G9SX-GS226-T15-RC from Omron is engineered to deliver precise safety control with an extended OFF-delay time of 150 seconds, allowing controlled deactivation of connected machinery. With a rated voltage of 24 VDC and low power consumption of just 2 W max, this safety relay unit ensures efficient energy usage without compromising performance. The operating time is 30 ms max, and response time is 10 ms max, making it ideal for time-critical safety applications in Indian automation setups such as packaging, printing, and assembly lines.
Built to operate in tough factory conditions, the G9SX-GS226-T15-RC withstands vibrations ranging from 10 to 55 Hz at 0.75 mm double amplitude and shock resistance of up to 300 m/sΒ² during destruction testing. Its operational range includes ambient temperatures from β10Β°C to 55Β°C and humidity levels between 25% to 85%, ensuring durability and stability in both high-heat and humid Indian environments. The relay unit is compact and secure, with a terminal tightening torque of 0.5 NΒ·m and weight of approximately 165 g, making it a perfect fit for space-limited control cabinets.
