Omron G7SA-5A1B DC24 Relay
The Omron G7SA-5A1B DC24 Relay offers dependable switching with a Flux tight housing, PCB terminal structure, and a 24 VDC 20.8 mA coil rating for stable operation. It features a 5PST-NO/SPST-NC contact form with Au platingοΌAg alloy contacts. The relay supports a 75 % max operate voltage, 10 % min. release voltage, and a 110 % maximum coil voltage rating. With Approx. 500 mW power consumption and a 250 VAC; 125 VDC maximum contact voltage, it ensures durable and consistent performance. Manufactured by Omron and listed under Omron Relay solutions, this model belongs to the G7SA Series.
| Brand | Omron |
| Product | Relay |
| Model Number | G7SA-5A1B DC24 |
Omron G7SA-5A1B DC24 Relay - Technical Specifications
| Specification | Value |
|---|---|
| Terminal Structure | PCB terminal |
| Degree Of Protection | Flux tight |
| Coil Resistance | 1152 Ξ© |
| Operate Voltage Set Voltage | 75 % max |
| Release Voltage Reset Voltage | 10 % min. |
| Max Contact Voltage | 250 VAC; 125 VDC |
| Contact Form | 5PST-NO/SPST-NC |
| Mounting Method | Socket, Soldering |
| Coil Ratings | 24 VDC 20.8 mA |
| Contact Material | Au platingοΌAg alloy |
| Power Consumption | Approx. 500 mW |
| Maximum Voltage | 110 % |
| Contact Resistance | 100 mΞ© max. (Voltage drop method with 5 VDC 1 A) |
| Operating Time | 20 ms max. (With rated operating power applied, 23 β, not including contact bounce) |
| Reset Time | 20 ms max. (With rated operating power applied, 23 β, not including contact bounce) |
| Ambient Temperature Operating | -40 to 85 β (with no freezing or condensation) |
| Ambient Humidity Operating | 5 to 85 % |
| Weight | Approx. 25 g |
The Omron G7SA-5A1B DC24 offers robust performance and durability for industrial automation applications. With a flux-tight construction, this relay features PCB terminal connections for secure and efficient wiring. Operating at 24 VDC with 20.8 mA coil rating, it ensures high efficiency with a power consumption of approximately 500 mW.
The relay supports both 250 VAC and 125 VDC loads and comes with a 5PST-NO/SPST-NC contact configuration made from Au plating + Ag alloy, ensuring superior conductivity. With an operating time of 20 ms max and a reset time of 20 ms max, it ensures fast response in critical operations. The insulation resistance of 100 mΞ© max. (Voltage drop method with 5 VDC 1 A) and a wide ambient temperature range of -40 to 85 β make it a reliable choice for various industrial settings.
This relay is designed for socket and soldering mounting and weighs approximately 25 g. For more detailed information, visit the official Omron G7SA-5A1B DC24 product page and see why it's a trusted solution for industrial automation needs.
