Omron G7J-4A-B DC24 Relay
The Omron G7J-4A-B DC24 Relay offers dependable switching with a Closed type (cover) housing, Screw terminal structure, and a 24 VDC 83 mA coil rating for stable operation. It features a 4PST-NO contact form with Ag alloy contacts and a Double break mechanism designed for high-reliability control circuits. The relay supports a 75 % max operate voltage, 10 % min release voltage, and a 110 % maximum coil voltage rating. With Approx. 2 W power consumption and a 250 VAC; 125 VDC maximum contact voltage, it ensures durable and consistent performance. Manufactured by Omron and listed under Omron Relay solutions, this model belongs to the G7J Series..
| Brand | Omron |
| Product Type | Relay |
| Model Number | G7J-4A-B DC24 |
Omron G7J-4A-B DC24 Relay - Technical Specifications
| Specification | Value |
|---|---|
| Degree of protection | Closed type (cover) |
| Terminal structure | Screw terminal |
| Coil ratings | 24 VDC 83 mA |
| Coil resistance | 288 Ξ© |
| Operate voltage (Set voltage) | 75 % max |
| Release voltage (Reset voltage) | 10 % min |
| Maximum voltage | 110 % |
| Power consumption | Approx. 2 W |
| Max. contact voltage | 250 VAC; 125 VDC |
| Contact form | 4PST-NO |
| Contact method | Double break |
| Contact material | Ag alloy |
| Contact resistance | 100 mΞ© max. (Voltage drop method with 5 VDC 1 A) |
| Operating time | 50 ms max. (With rated operating power applied, 23 β, not including contact bounce) |
| Reset time | 50 ms max. (With rated operating power applied, 23 β, not including contact bounce) |
| Ambient temperature (Operating) | -25 to 60 β (with no freezing or condensation) |
| Ambient humidity (Operating) | 5 to 85 % |
| Mounting method | W-bracket mounting |
| Weight | Approx. 165 g |
Built for demanding control environments, the G7J-4A-B DC24 features a robust 4PST-NO contact configuration and uses a double break contact method for dependable circuit control. Operating on a 24 VDC coil voltage at 83 mA with a coil resistance of 288 Ξ©, this Omron safety relay offers power efficiency with a consumption of just 2 W. The contacts, made of Ag alloy, provide excellent conductivity and long-term durability for both 250 VAC and 125 VDC loads.
Engineered with precision, the G7J-4A-B DC24 maintains a contact resistance of 100 mΞ© max and ensures operating/reset times under 50 ms. Its rugged closed-type cover construction protects internal components in harsh environments. The relay functions reliably within an ambient temperature range of -25 to 60Β°C and humidity levels of 5 to 85%, making it suitable for diverse industrial conditions. Installation is seamless with W-bracket mounting, and at just 165 g, it fits easily into compact panels without compromising on performance.
Engineers across industries trust the Omron G7J-4A-B DC24 for its consistency, longevity, and compliance with industrial safety norms.
View full product documentation on Omronβs official page to explore more technical resources and certifications.
