Omron G7J-2A2B-B DC24 Relay
The Omron G7J-2A2B-B DC24 Relay offers dependable switching with a Closed type (cover) housing, Screw terminal structure, and a 24 VDC 83 mA coil rating for stable operation. It features a DPST-NO/DPST-NC contact form with Ag alloy contacts and a Double break mechanism designed for high-reliability control circuits. The relay supports a 75 % max operate voltage, 10 % min release voltage, and a 110 % maximum coil voltage rating. With Approx. 2 W power consumption and a 250 VAC; 125 VDC maximum contact voltage, it ensures durable and consistent performance. Manufactured by Omron and listed under Omron Relay solutions, this model belongs to the G7J Series..
| Brand | Omron |
| Product | Relay |
| Model Number | G7J-2A2B-B DC24 |
Omron G7J-2A2B-B DC24 Relay - Technical Specifications
| Specification | Value |
|---|---|
| Terminal Structure | Screw terminal |
| Degree Of Protection | Closed type (cover) |
| Coil Resistance | 288 Ω |
| Operate Voltage Set Voltage | 75 % max |
| Release Voltage Reset Voltage | 10 % min |
| Max Contact Voltage | 250 VAC; 125 VDC |
| Contact Method | Double break |
| Contact Form | DPST-NO/DPST-NC |
| Mounting Method | W-bracket mounting |
| Coil Ratings | 24 VDC 83 mA |
| Contact Material | Ag alloy |
| Power Consumption | Approx. 2 W |
| Maximum Voltage | 110 % |
| Contact Resistance | 100 mΩ max. (Voltage drop method with 5 VDC 1 A) |
| Operating Time | 50 ms max. (With rated operating power applied, 23 ℃, not including contact bounce) |
| Reset Time | 50 ms max. (With rated operating power applied, 23 ℃, not including contact bounce) |
| Ambient Temperature Operating | -25 to 60 ℃ (with no freezing or condensation) |
| Ambient Humidity Operating | 5 to 85 % |
| Weight | Approx. 165 g |
With its robust configuration, the G7J-2A2B-B DC24 from Omron features a DPST-NO/DPST-NC contact form and double break Ag alloy contacts engineered for reliable switching of both AC and DC loads up to 250 VAC and 125 VDC. Operating on 24 VDC coil voltage and drawing just 83 mA, this safety relay ensures energy efficiency while delivering high performance. It includes a coil resistance of 288 Ω, operate voltage of 75% max, and release voltage of 10% min, offering dependable switching behavior even in fluctuating supply conditions.
Built for industrial environments, the G7J-2A2B-B DC24 operates within a wide temperature range of -25°C to 60°C and relative humidity between 5% to 85%. Its closed-type cover design and screw terminal structure enable secure wiring and enhanced protection, while W-bracket mounting ensures quick and sturdy installation. With a maximum switching time of 50 ms and reset time of 50 ms, it’s well-suited for time-sensitive operations across various industrial applications.
Trusted by OEMs and panel builders alike, the Omron G7J-2A2B-B DC24 safety relay combines reliability, durability, and performance in a compact 165 g frame.
View complete specifications on the official Omron product page.
