Omron G4Q-212S AC200/(220) Relay
The Omron G2R-2-SNI DC24 (S) Relay delivers reliable switching with a Closed type (cover), Plug-in terminal structure, and a 24 VDC 25.6 mA coil rated for stable operation. It features a DPDT contact form with a 1113 Ξ© maximum resistance, ensuring low-loss conduction. The relay supports a 70% max. operate voltage and 15% min. release voltage, offering consistent electrical response. Designed for panel integration, its Socket mounting enhances installation convenience. Manufactured by Omron and listed under Omron Relay solutions, this model is listed under the Omron G2R Series.
| Brand | Omron |
| Product Type | Relay |
| Model Number | G4Q-212S AC200/(220) |
Omron G4Q-212S AC200/(220) Relay - Technical Specifications
| Specification | Value |
|---|---|
| Terminal structure | Plug-in terminal |
| Degree of protection | Closed type (cover) |
| Coil resistance | 671 Ξ© |
| Operate voltage (Set voltage) | 80% max. |
| Release voltage (Reset voltage) | 10% min. |
| Max. contact voltage | 250 VAC 250 VDC |
| Max. Contact Current | AC: 5 A DC: 5 A |
| Contact method | Single |
| Contact form | DPDT |
| Contact resistance | 50 mΞ© max. (Voltage drop method with 5 VDC 1 A) |
| Operating time | 60 ms max. (With rated operating power applied, 23 β, not including contact bounce) |
| Maximum operating frequency | Mechanical: 1200 time/h Rated load: 1200 time/h |
| Ambient temperature (Operating) | -10 to 55 β (with no freezing or condensation) |
| Ambient humidity (Operating) | 5 to 85% RH |
| Mounting method | Socket |
| Coil ratings | 200 VAC 50 Hz 37 mA 200 VAC 60 Hz 32 mA 220 VAC 60 Hz 36.8 mA |
| Coil Maximum voltage | 110 % |
| Contact material | Ag alloy |
| Power consumption | Approx. 13.5 VA Initial/Approx. 6.4 VA Rating |
| Insulation resistance | Between coil and contacts: 100 MΞ© min. (at 500 VDC) Between contacts of different polarity: 100 MΞ© min. (at 500 VDC) Between contacts of the same polarity: 100 MΞ© min. (at 500 VDC) |
| Coil Contact rated load | 220 VAC 5 A (Resistive load) 220 VAC 3 A (Inductive load (cosΟ = 0.4)) 24 VDC 5 A (Resistive load) 24 VDC 4 A (Inductive load (L/R = 7 ms)) |
| Contact Maximum switching power | 1100 VA (Resistive load) 660 VA (Inductive load (cosΟ = 0.4)) 120 W (Resistive load) 100 W (Inductive load (L/R = 7 ms)) |
| Weight | Approx. 340 g |
