Omron G3TA-ODX02S-US DC12 Solid-state Relay
The Omron G3TA-ODX02S-US DC12 Solid-state Relay (SSR) delivers 24 VDC input, 5 to 48 VDC output, and 0.01 to 2 A (at 60 β) load performance reliably. This relay features a Single-phase, 2-element structure with Photocoupler isolation, an Equipped zero-cross function for noise-free switching, and an Equipped operating indicator for real-time status monitoring. Its Plug-in terminal socket simplifies installation, while 12 A (60 Hz 1 cycle) inrush current resistivity, it ensures stable operation across its 19.2 to 26.4 VDC. input range. Manufactured by Omron and listed under Omron Solid State Relay solutions, this model belongs to the G3TA Series.
| Brand | Omron |
| Product Type | Solid State Relay |
| Model Number | G3TA-ODX02S-US DC12 |
Omron G3TA-ODX02S-US DC12 Solid-state Relay - Technical Specifications
| Specification | Value |
|---|---|
| Product classification | Relay compatible |
| Number of phases | Single-phase |
| Number of elements | 2 |
| Isolation method | Photocoupler |
| Zero cross function | Equipped |
| Operating indicator | Equipped |
| Terminal structure | Plug-in terminal |
| Mounting | socket |
| Input Rated Voltage | 24 VDC |
| Input Operating voltage range | 19.2 to 26.4 VDC. |
| Input current | 6.5 kΩ±20% |
| Input Operate voltage | 19.2 V max.DC |
| Input Release voltage | 2 V min.DC |
| Output Rated load voltage | 5 to 48 VDC |
| Output Load voltage range | 4 to 60 VDC |
| Output Minimum load current | 100 Β΅A to 3 A |
| Output Load Current | 0.01 to 2 A (at 60 β) |
| Output Inrush current resistivity | 12 A (60 Hz 1 cycle) |
| Operate time | 0.5 ms max. |
| Release time | 2 ms max. |
| Output ON voltage drop | Main circuit: 1.6 V max. (RMS) |
| Leakage current | 5 Β΅A max. |
| Insulation resistance | 100 MΞ© min. (at 500 VDC) |
| Dielectric strength | 2000 VAC 50/60 Hz 1 min |
| Vibration resistance | 10 to 55 to 10 Hz, 0.175 mm single amplitude (0.75 mm double amplitude) |
| Shock resistance | 1000 m/s 2 (DIN Track mounting) |
| Ambient temperature (Operating) | -30 to 80 β (with no freezing or condensation) |
| Ambient temperature (Storage) | -30 to 100 β (with no freezing or condensation) |
| Ambient humidity (Operating) | 45 to 85% RH |
| Weight | Approx. 16 g |
