Omron G3RV-SR700-A DC24 Solid-state Relay
Omron G3RV-SR700-A DC24 is a single-phase, 2-element solid state relay using photo volt coupler isolation with a 24 VDC rated input. The supplied output rating covers AC100 to 240 V at 50/60 Hz and DC5 to 24 V, with corresponding operating ranges of AC75 to 264 V and DC3 to 26.4 V. Another load field lists 100 µA to 3 A, while the output-current field specifies 30 A for 10 ms and inrush current resistivity is 30 A for one 60 Hz cycle. The relay uses Push-In Plus terminals and supports DIN track or screw mounting. The G3RV-SR700-A DC24 dual-output belongs to the SSR switching range from Omron industrial automation devices.
| Brand | Omron |
| Product | Solid State Relay |
| Model Number | G3RV-SR700-A DC24 |
Omron G3RV-SR700-A DC24 Solid-state Relay - Technical Specifications
| Specification | Value |
|---|---|
| Number Of Phases | Single-phase |
| Isolation Method | Photo volt coupler |
| Mounting | DIN track mounting,Screw mounting |
| Operating Indicator | Equipped |
| Terminal Structure | Push-In Plus Terminal Block |
| Product Classification | Relay compatible Solid State Relay |
| Number Of Elements | 2 |
| Zero Cross Function | Equipped |
| Input Rated Voltage | 24 VDC |
| Input Current | DC: 9.0 mA |
| Input Operate Voltage | 21.6 VDC max. |
| Input Release Voltage | 1 VDC min. |
| Output Rated Load Voltage | AC100~240V (50/60Hz) DC5~24V |
| Output Load Voltage Range | AC75~264V (50/60Hz) DC3~26.4V |
| Output Minimum Load Current | 100 µA to 3 A |
| Output Load Current | 30 A (10 ms) |
| Output Inrush Current Resistivity | 30 A (60 Hz 1 cycle) |
| Operate Time | 10 µA max. (at 24 VDC) |
| Release Time | 1/2 cycle of load power source + 1 ms max. |
| Output On Voltage Drop | Main circuit: 1.6 V max. (RMS) Alarm output: 1.8 V max. |
| Leakage Current | Main circuit: 2 mA max. (at 200 VAC) Alarm output: 0.1 mA max. |
| Insulation Resistance | 100 MΩ min. (at 500 VDC) |
| Dielectric Strength | 2500 VAC 50/60 Hz 1 min |
| Vibration Resistance | 10 to 55 to 10 Hz, 0.175 mm single amplitude (0.75 mm double amplitude) |
| Shock Resistance | 300 m/s 2 (DIN Track mounting) |
| Ambient Temperature Operating | -30 to 80 ℃ (with no freezing or condensation) |
| Ambient Temperature Storage | -30 to 100 ℃ (with no freezing or condensation) |
| Ambient Humidity Operating | 45 to 85% RH |
| Weight | Approx. 30 g |
The Omron G3RV-SR500-D AC/DC24 Solid State Relay is a single-phase, 2-element model using photo volt coupler isolation, DIN track or screw mounting, and a Push-In Plus Terminal Block. The supplied rated input is 24 VDC. Input current is listed separately as 5.0 mA at 50 Hz, 5.1 mA at 60 Hz, and 4.3 mA for DC. Input operate voltage is 21.6 VDC max. and release voltage is 1 VDC min. Its output is rated from 5 to 24 VDC, with a 3 to 26.4 VDC load-voltage range. A separate load field lists 100 µA to 3 A, while the output-current field gives 3 A for 10 ms. Output inrush current resistivity is 30 A for one 60 Hz cycle. An operating indicator and zero-cross function are both equipped.
Main-circuit output ON voltage drop is 1.6 V max. RMS and the alarm-output value is 1.8 V max. Main-circuit leakage current is 2 mA max. at 200 VAC, while alarm-output leakage is 0.1 mA max. Insulation resistance is 100 MΩ min. at 500 VDC and dielectric strength is 2500 VAC at 50/60 Hz for 1 minute. For the related SR500-D model whose input-current field is listed as 9.0 mA DC, see G3RV-SR500-D DC24.
