Omron G3RV-SR500-D AC/DC24 Solid-state Relay
Omron G3RV-SR500-D AC/DC24 is a single-phase, 2-element solid state relay with photo volt coupler isolation and a Push-In Plus Terminal Block. Its rated input is 24 VDC, while the supplied output is 5 to 24 VDC with a 3 to 26.4 VDC load voltage range. Input current is listed as 5.0 mA at 50 Hz, 5.1 mA at 60 Hz, and 4.3 mA for DC. Another load field lists 100 µA to 3 A, while the output-current field specifies 3 A for 10 ms. Inrush current resistivity is 30 A for one 60 Hz cycle. The G3RV-SR500-D AC/DC24 configuration sits in the Solid state switching family from Omron automation relay products.
| Brand | Omron |
| Product | Solid State Relay |
| Model Number | G3RV-SR500-D AC/DC24 |
Omron G3RV-SR500-D AC/DC24 Solid-state Relay - Technical Specifications
| Specification | Value |
|---|---|
| Number Of Phases | Single-phase |
| Isolation Method | Photo volt coupler |
| Mounting | DIN track mounting,Screw mounting |
| Operating Indicator | Equipped |
| Terminal Structure | Push-In Plus Terminal Block |
| Product Classification | Relay compatible Solid State Relay |
| Number Of Elements | 2 |
| Zero Cross Function | Equipped |
| Input Rated Voltage | 24 VDC |
| Input Current | AC (50 Hz): 5.0 mA AC (60 Hz): 5.1 mA DC: 4.3 mA |
| Input Operate Voltage | 21.6 VDC max. |
| Input Release Voltage | 1 VDC min. |
| Output Rated Load Voltage | 5 to 24 VDC |
| Output Load Voltage Range | 3 to 26.4 VDC |
| Output Minimum Load Current | 100 µA to 3 A |
| Output Load Current | 3 A (10 ms) |
| Output Inrush Current Resistivity | 30 A (60 Hz 1 cycle) |
| Operate Time | 6 µA max. (at 24 VDC) |
| Release Time | 1/2 cycle of load power source + 1 ms max. |
| Output On Voltage Drop | Main circuit: 1.6 V max. (RMS) Alarm output: 1.8 V max. |
| Leakage Current | Main circuit: 2 mA max. (at 200 VAC) Alarm output: 0.1 mA max. |
| Insulation Resistance | 100 MΩ min. (at 500 VDC) |
| Dielectric Strength | 2500 VAC 50/60 Hz 1 min |
| Vibration Resistance | 10 to 55 to 10 Hz, 0.175 mm single amplitude (0.75 mm double amplitude) |
| Shock Resistance | 300 m/s 2 (DIN Track mounting) |
| Ambient Temperature Operating | -30 to 80 ℃ (with no freezing or condensation) |
| Ambient Temperature Storage | -30 to 100 ℃ (with no freezing or condensation) |
| Ambient Humidity Operating | 45 to 85% RH |
| Weight | Approx. 30 g |
The Omron G3R-ODX02SN-UTU DC5-24 Solid State Relay combines a single-phase, 2-element structure with photocoupler isolation, socket mounting, plug-in terminals, an operating indicator, and an equipped zero-cross function. Rated input is 5 to 24 VDC and the input operating range is 4 to 32 VDC. Input current is specified as 15 mA max., with 4 VDC max. operate voltage and 1 VDC min. release voltage. The source lists 75 to 264 VDC as the rated output voltage and separately lists 4 to 60 VDC as another output-voltage range. A 100 µA to 3 A field is also present, together with another output-load field of 0.1 to 2 mA. Output inrush current resistivity is 30 A for one 60 Hz cycle. The supplied values are retained without silently correcting their field relationships.
Switching timing is 20 ms max. for operate and 15 ms max. for release. Main-circuit output ON voltage drop is 1.6 V max. RMS, leakage current is 5 µA max., and insulation resistance is 100 MΩ min. at 500 VDC. Dielectric strength is specified as 4000 VAC at 50/60 Hz for 1 minute. Operating temperature ranges from -30 to 80°C without freezing or condensation. The related OA202SZN-UTU entry carries the same principal electrical values in the supplied data. For that corresponding model, see G3R-OA202SZN-UTU DC5-24.
