Omron G3R-ODX02SN-UTU DC5-24 Solid-state Relay
Omron G3R-ODX02SN-UTU DC5-24 is a single-phase I/O solid state relay built with two elements, photocoupler isolation, and socket mounting. Its input is rated from 5 to 24 VDC and operates across 4 to 32 VDC, with 15 mA max. input current, 4 VDC max. operate voltage, and 1 VDC min. release voltage. The supplied output fields list 75 to 264 VDC rated output, a separate 4 to 60 VDC range, and 0.1 to 2 mA in another load field. Output inrush current resistivity is 30 A for one 60 Hz cycle, while an operating indicator and zero-cross function are equipped. The G3R-ODX02SN-UTU DC5-24 I/O falls under the electronic relay lineup from Omron industrial interface products.
| Brand | Omron |
| Product | Solid State Relay |
| Model Number | G3R-ODX02SN-UTU DC5-24 |
Omron G3R-ODX02SN-UTU DC5-24 Solid-state Relay - Technical Specifications
| Specification | Value |
|---|---|
| Number Of Phases | Single-phase |
| Isolation Method | Photocoupler |
| Mounting | socket |
| Operating Indicator | Equipped |
| Terminal Structure | Plug-in terminal |
| Product Classification | Relay compatible High-speed response speed |
| Number Of Elements | 2 |
| Zero Cross Function | Equipped |
| Input Rated Voltage | 5 to 24 VDC |
| Input Current | 15 mA max. |
| Input Operate Voltage | 4 VDC max. |
| Input Release Voltage | 1 VDC min. |
| Output Rated Load Voltage | 75 to 264 VDC |
| Output Load Voltage Range | 4 to 60 VDC |
| Output Minimum Load Current | 100 µA to 3 A |
| Output Load Current | 0.1 to 2 mA |
| Output Inrush Current Resistivity | 30 A (60 Hz 1 cycle) |
| Operate Time | 20 ms max. |
| Release Time | 15 ms max. |
| Output On Voltage Drop | Main circuit: 1.6 V max. (RMS) |
| Leakage Current | 5 µA max. |
| Insulation Resistance | 100 MΩ min. (at 500 VDC) |
| Dielectric Strength | 4000 VAC 50/60 Hz 1 min |
| Vibration Resistance | 10 to 55 to 10 Hz, 0.175 mm single amplitude (0.75 mm double amplitude) |
| Shock Resistance | 1000 m/s 2 (DIN Track mounting) |
| Ambient Temperature Operating | -30 to 80 ℃ (with no freezing or condensation) |
| Ambient Temperature Storage | -30 to 100 ℃ (with no freezing or condensation) |
| Ambient Humidity Operating | 45 to 85% RH |
| Weight | Approx. 18 g |
The Omron G3R-IDZR1SN-UTU DC12-24 Solid State Relay is a single-phase, 2-element socket relay with photocoupler isolation, plug-in terminals, an operating indicator, and an equipped zero-cross function. Rated input voltage is 12 to 24 VDC with a 6.6 to 32 VDC input operating range. Input current is 8 mA max., input operate voltage is 6.6 VDC max., and release voltage is 3.6 VDC min. The output is rated from 4 to 32 VDC, while another supplied output-voltage field lists 4 to 60 VDC. The load-current field is specified as 0.1 to 100 mA. Output inrush current resistivity is listed as 12 A for one 60 Hz cycle. These values are retained as supplied without reconciling the two output-voltage fields.
Operate time is 0.5 ms max. and release time is 2 ms max. Main-circuit output ON voltage drop is 1.6 V max. RMS, while leakage current is 5 µA max. Insulation resistance is 100 MΩ min. at 500 VDC and dielectric strength is 4000 VAC at 50/60 Hz for 1 minute. Ambient operating temperature ranges from -30 to 80°C without freezing or condensation. For another G3R model using a 12 to 24 VDC input but a 15 ms max. switching-time specification, see G3R-IDZR1SN-1 DC12-24.
