Omron G3NE-210T-US DC5 Solid-state Relay
The Omron G3NE-210T-US DC5 Solid-state Relay (SSR) delivers 5 VDC input, 100 to 240 VAC output, and 0.1 to 10 A (With heat sink at 40 β) 0.1 to 5 A (Without a heat sink at 40 β) load performance reliably. This relay features a Single-phase, 3-element structure with Phototriac isolation, an Equipped zero-cross function for noise-free switching, and an Not equipped operating indicator for real-time status monitoring. Its Tab terminal (Input: #110, Output: #250) socket simplifies installation, while 150 A (60 Hz 1 cycle) inrush current resistivity, it ensures stable operation across its 4 to 6 VDC input range. Manufactured by Omron and listed under Omron Solid State Relay solutions, this model belongs to the G3NE Series.
| Brand | Omron |
| Product Type | Solid State Relay |
| Model Number | G3NE-210T-US DC5 |
Omron G3NE-210T-US DC5 Solid-state Relay - Technical Specifications
| Specification | Value |
|---|---|
| Product classification | For Single-phase Heater |
| Number of phases | Single-phase |
| Number of elements | 3 |
| Isolation method | Phototriac |
| Zero cross function | Equipped |
| Operating indicator | Not equipped |
| Terminal structure | Tab terminal (Input: #110, Output: #250) |
| Mounting | Screw mounting |
| Input Rated Voltage | 5 VDC |
| Input Operating voltage range | 4 to 6 VDC |
| Input current | 250 kΩ±20% |
| Input Operate voltage | 4 VDC max. |
| Input Release voltage | 1 VDC min. |
| Output Rated load voltage | 100 to 240 VAC |
| Output Load voltage range | 75 to 264 VAC |
| Output Minimum load current | 0.2 VDC |
| Output Load Current | 0.1 to 10 A (With heat sink at 40 β) 0.1 to 5 A (Without a heat sink at 40 β) |
| Output Inrush current resistivity | 150 A (60 Hz 1 cycle) |
| Operate time | 1/2 cycle of load power source + 1 ms max. |
| Release time | 1/2 cycle of load power source + 1 ms max. |
| Output ON voltage drop | 1.6 V max. (RMS) |
| Leakage current | 2 mA max. (at 100 VAC) 5 mA max. (at 200 VAC) |
| Insulation resistance | 100 MΞ© min. (at 500 VDC) |
| Dielectric strength | 2000 VAC 50/60 Hz 1 min |
| Vibration resistance | 10 to 55 to 10 Hz, 0.175 mm single amplitude (0.75 mm double amplitude) |
| Shock resistance | 1000 m/s 2 (DIN Track mounting) |
| Ambient temperature (Operating) | -30 to 80 β (with no freezing or condensation) |
| Ambient temperature (Storage) | -30 to 100 β (with no freezing or condensation) |
| Ambient humidity (Operating) | 45 to 85% RH |
| Weight | Approx. 37g |
