Omron EE-SX976-C1 Slot-Type Photomicrosensor
The EE-SX976-C1 Slot-type Photomicrosensor is a through-beam sensor with an F-shaped slot design and a 5 mm sensing distance, supporting NPN output and 5 to 24 VDC operation with Light-ON and Dark-ON modes. Manufactured by Omron, this Omron Slot-type Photomicrosensor is part of the Omron Photoelectric Sensors category and belongs to the Omron EE Series.
| Brand | Omron |
| Product | Photomicro Sensors |
| Model Number | EE-SX976-C1 |
Omron EE-SX976-C1 Slot-Type Photomicrosensor – Technical Specifications
| Specification | Value |
|---|---|
| Type | F-shaped |
| Sensing Method | Throughbeam with slot |
| Sensing Distance | 5 mm |
| Power Supply Voltage | 5 to 24 VDC |
| Control Output (Output Type) | NPN |
| Connection Method | Connector (4 poles) |
| Current Consumption | 21 mA |
| Operation Mode | With both Dark-ON and Light-ON |
| Control Output (Residual Voltage) | at 5 mA load current: 0.4 V max. at 50 mA load current: 1.0 V max. |
| Control Output (Load Current) | 50 mA max. |
| Indicator | Light indicator (orange) |
| Luminous Method | Non-modulated |
| Ambient Temperature (Operating) | -25 to 55 ℃ (with no freezing or condensation) |
| Ambient Temperature (Storage) | -30 to 80 ℃ (with no freezing or condensation) |
| Ambient Humidity (Operating) | 5 to 85 % (with no freezing or condensation) |
| Ambient Humidity (Storage) | 5 to 95 % (with no freezing or condensation) |
| Vibration Resistance | Destruction: 10 to 2000 Hz, 0.75 mm single amplitude in each X, Y, and Z directions (15 min, 10 cycle) |
| Shock Resistance | Destruction: 500 m/s2 for 3 times each in X, Y, and Z directions |
| Degree Of Protection | IP50 |
| Material | Case: Polybutylene terephthalate (PBT) Cover: Polybutylene terephthalate (PBT) Emitter/Receiver: Polycarbonate (PC) |
The Omron EE-SX976-C1 is a compact slot-type photomicrosensor designed for accurate object detection in limited installation spaces. Using a through-beam sensing method with a fixed 5 mm slot, it delivers stable detection performance in automation systems requiring precise positioning and repeatability. The F-shaped housing supports easy mounting in confined mechanical assemblies.
This Omron Slot-type Photomicrosensor provides selectable Light-ON and Dark-ON operation and features a NPN open-collector output suitable for standard PLC and controller inputs. Connector-based wiring simplifies installation and replacement, helping reduce maintenance time in automated machinery and production equipment.
Built with durable PBT and polycarbonate materials, the EE-SX976-C1 operates reliably across ambient temperatures from -25°C to 55°C and carries an IP50 protection rating. It is commonly used in automated machines, part detection, and industrial equipment where compact size, consistent sensing, and dependable electrical performance are essential.
