Omron E5GN-R1T-C Digital Temperature Controller
The Omron E5GN-R1T-C Temperature Controller is a compact and precise Basic-type Digital Temperature Controller designed for stable, fast-response industrial temperature control. Its 48 Γ 24 mm design supports a versatile operates on 100 to 240 VAC, 50/60 Hz with an allowable range of 85% to 110% of rated supply voltage, it provides ON/OFF control or 2-PID control (with auto-tuning) for consistent temperature stability. The controller features Voltage output (for driving SSR), , 1 Point auxiliary outputs, Digital setting using front panel keys, 11-segment digital display for improved visibility, and Screwless Clamp Terminal Blocks wiring for easy panel integration. Manufactured by Omron, part of the Omron Temperature Controller ecosystem within the Omron E5GN Series.
| Brand | Omron |
| Product Type | Temperature Controller |
| Model Number | E5GN-R1T-C |
Omron E5GN-R1T-C Temperature Controller - Technical Specifications
| Specification | Value |
|---|---|
| Shape | 48 Γ 24 mm |
| Power supply voltage | 100 to 240 VAC, 50/60 Hz |
| Operating voltage range | 85% to 110% of rated supply voltage |
| Power consumption | 100 to 240 VAC: 5.5 VA (max.) |
| Control method | ON/OFF control or 2-PID control (with auto-tuning) |
| Input Type/Temperature input | Thermocouple: K, J, T, E, L, U, N, R, S, B, W, or PL II Platinum resistance thermometer: Pt100 or JPt100 Infrared temperature sensor (ES1B): 10 to 70Β°C, 60 to 120Β°C, 115 to 165Β°C, or 140 to 260Β°C Voltage input: 0 to 50 mV |
| Control output 1 | Voltage output (for driving SSR) |
| Number of total auxiliary output | 1 Point |
| Setting method | Digital setting using front panel keys |
| Indication method | 11-segment digital display and individual indicators (7-segment display also possible) Character height: PV: 7.5 mm, SV: 3.6 mm |
| Insulation resistance | 20 MΞ© min. (at 500 VDC) |
| Dielectric strength | 2,300 VAC, 50 or 60 Hz for 1 min (between terminals with different charge) |
| Vibration resistance | Malfunction: 10 to 55 Hz, 20 m/s2 for 10 min each in X, Y, and Z directions Destruction: 10 to 55 Hz, 0.75-mm single amplitude for 2 hrs each in X, Y, and Z directions |
| Shock resistance | Malfunction: 100 m/s2, 3 times each in X, Y, and Z directions Destruction: 300 m/s2, 3 times each in X, Y, and Z directions |
| Ambient temperature (Operating) | β10 to 55Β°C (with no condensation or icing), for 3-year warranty: β10 to 50Β°C |
| Ambient temperature (Storage) | β25 to 65Β°C (with no condensation or icing) |
| Ambient humidity (Operating) | 25% to 85% |
| Degree of protection | Front panel: IP66, Rear case: IP20, Terminals: IP00 |
| Case color | Black |
| Terminal type | Screwless Clamp Terminal Blocks |
| Weight | Controller: Approx. 210 g, Adapter: Approx. 4 g Γ 2 |
The Omron E5GN-R1T-C is frequently assessed alongside other units in the Digital Temperature Controllers group because they share comparable sensor inputs, panel depth behaviour, and loop-control characteristics. Engineers often evaluate Omron E5GN-R1T (48 Γ 24 mm, ON/OFF control or 2-PID control (with auto-tuning), 100 to 240 VAC, 50/60 Hz, Relay output, 11-segment digital display and individual indicators (7-segment display also possible) Character height: PV: 7.5 mm, SV: 3.6 mm), Omron E5GN-Q1T (48 Γ 24 mm, ON/OFF control or 2-PID control (with auto-tuning), 100 to 240 VAC, 50/60 Hz, Voltage output (for driving SSR), 11-segment digital display and individual indicators (7-segment display also possible) Character height: PV: 7.5 mm, SV: 3.6 mm), and Omron E5GN-Q1T-C (48 Γ 24 mm, ON/OFF control or 2-PID control (with auto-tuning), 100 to 240 VAC, 50/60 Hz, Voltage output (for driving SSR), 11-segment digital display and individual indicators (7-segment display also.
