Omron EJ1C-EDUA-NFLK Modular Temperature Controller

The Omron EJ1C-EDUA-NFLK Temperature Controller is a modular controller designed as part of an industrial temperature control system. Its module-type construction operates from 24 VDC, with an allowable supply range of 85% to 110% of the rated power supply voltage. The modular format supports integration with other components in the EJ1 temperature control architecture without requiring a conventional front-panel controller format. An M3 terminal connection provides the specified electrical interface for installation. The EJ1C-EDUA-NFLK belongs to the EJ1C configuration within the modular temperature controller range from Omron industrial control products.

Brand	Omron
Product	Temperature Controllers
Model Number	EJ1C-EDUA-NFLK

Omron EJ1C-EDUA-NFLK Temperature Controller - Technical Specifications

Specification	Value
Shape	Module type
Power supply voltage	24 VDC
Operating voltage range/ Allowable voltage variable range	85 to 110% of the power supply voltage
Insulation resistance	20 MΩ min. (at 500 VDC)
Dielectric strength	600 VAC, 50/60 Hz for 1 min between current-carrying terminals of different polarity
Vibration resistance	10 to 55 Hz, 20 m/s2 for 2 hours each in X, Y, and Z directions
Shock resistance	150 m/s2, 3 times each in 6 directions
Ambient temperature (Operating)	−10°C to 55°C
Ambient temperature (Storage)	−25°C to 65°C (with no icing or condensation)
Ambient humidity (Operating)	25% to 85% (with no condensation)
Degree of protection	IP20
Terminal type	M3 terminal
Weight	Controller: Approx. 210 g, Adapter: Approx. 4 g × 2
