Omron E5CD-RX2D6M-002 Digital Temperature Controller
The Omron E5CD-RX2D6M-002 Temperature Controller is a compact and precise Digital Temperature Controller designed for stable, fast-response industrial temperature control. Its 48 Γ 48 mm design supports a versatile 1 point input for accurate sensing across multiple temperature applications. Operating on 24 VAC, 50/60 Hz; 24 VDC with an allowable range of 85% to 110% of rated supply voltage, it provides ON/OFF or 2-PID control with auto-tuning for consistent temperature stability. The controller includes a Relay output, 2 auxiliary outputs, Digital setting using front panel keys, 11-segment digital display for clear visibility, and Screw terminal blocks for easy and secure panel integration. Manufactured by Omron, part of the Omron Temperature Controller ecosystem within the Omron E5CD Series.
| Brand | Omron |
| Product Type | Temperature Controller |
| Model Number | E5CD-RX2D6M-002 |
Omron E5CD-RX2D6M-002 Temperature Controller - Technical Specifications
| Specification | Value |
|---|---|
| Shape | 48 Γ 48 mm |
| Power supply voltage | 24 VAC, 50/60 Hz; 24 VDC |
| Operating voltage range | 85% to 110% of rated supply voltage |
| Power consumption | 6.5 VA max. at 100 to 240 VAC, and 4.1 VA max. at 24 VAC or 2.3 W max. at 24 VDC |
| Control method | ON/OFF or 2-PID control with auto-tuning |
| Number of input points | 1 point |
| Input Type/Temperature input | Thermocouple: K, J, T, E, L, U, N, R, S, B, C/W, PLII Platinum resistance thermometer: Pt100, JPt100 Infrared Thermosensor: 10 to 70 β, 60 to 120 β, 115 to 165 β, 140 to 260 β |
| Control output 1 | Relay output |
| Control output 2 | None |
| Number of total auxiliary output | 2 |
| Setting method | Digital setting using front panel keys |
| Indication method | 11-segment digital display, individual indicators, and bar display |
| Insulation resistance | 20 MΞ© min. (at 500 VDC) |
| Dielectric strength | 3,000 VAC, 50/60 Hz for 1 min between terminals of different charge |
| Vibration resistance | 10 to 55 Hz, 20 m/s2 for 2 hrs each in X, Y, and Z directions |
| Shock resistance | 300 m/s2, 3 times each in X, Y, and Z directions |
| Ambient temperature (Operating) | -10 to 55 β (with no freezing or condensation) For 3-year warranty with standard mounting: -10 to 50 β (with no freezing or condensation) |
| Ambient temperature (Storage) | β25 to 65Β°C (with no condensation or icing) |
| Ambient humidity (Operating) | 25% to 85% |
| Degree of protection | IP66, Rear case: IP20, Terminals: IP00 |
| Terminal type | Screw terminal blocks |
| Weight | Controller: Approx. 210 g, Adapter: Approx. 4 g Γ 2 |
The Omron E5CD-RX2D6M-002 is frequently assessed alongside other units in the Digital Temperature Controllers group because they share comparable sensor inputs, panel depth behaviour, and loop-control characteristics. Engineers often evaluate Omron E5CD-CX2D6M-006 (48 Γ 48 mm, ON/OFF or 2-PID control with auto-tuning, 24 VAC, 50/60 Hz; 24 VDC, Linear current output, 11-segment digital display), Omron E5CD-CX2A6M-004 (48 Γ 48 mm, ON/OFF control or 2-PID control (with auto-tuning), 100 to 240 VAC, 50/60 Hz, Linear current output, 11-segment digital display, individual indicators, and bar display; Character height: PV: 14.9 mm, SV: 7.1 mm), and Omron E5CD-QX2A6M-001 (48 Γ 48 mm, ON/OFF or 2-PID control, 100 to 240 VAC, 50/60 Hz, Voltage output, 11-segment digital display) when selecting a controller that fits panel wiring, SSR/relay load stages, and enclosure thermal limits.
