Omron E5CC-CX2AUM-000 Temperature Controller
Omron E5CC-CX2AUM-000 Temperature Controller is a compact Digital Temperature Controller designed for stable and accurate industrial temperature regulation. Its DIN 48 × 48 mm body supports panel-based installation while providing fast-response temperature control for automation systems. Operating on 100 to 240 VAC at 50/60 Hz, this Omron PID Controller supports ON/OFF control and 2-PID control with auto-tuning for consistent thermal management. The controller includes linear current output, front-panel digital setting, and an 11-segment display for clear process monitoring. Manufactured by Omron automation, it belongs to the temperature control range and the E5CC series controllers used across industrial automation systems.
| Brand | Omron |
| Product | Temperature Controllers |
| Model Number | E5CC-CX2AUM-000 |
Omron E5CC-CX2AUM-000 Temperature Controller - Technical Specifications
| Specification | Value |
|---|---|
| Shape | DIN 48 × 48 mm |
| Power supply voltage | 100 to 240 VAC (50/60 Hz) |
| Operating voltage range/ Allowable voltage variable range | 85 to 110% of the power supply voltage |
| Power consumption | 5.2 VA max. at 100 to 240 VAC |
| Control method | ON/OFF control or 2-PID control (with auto-tuning) |
| Input Type/Temperature input | Thermocouple: K, J, T, E, L, U, N, R, S, B, C/W, or PL II Platinum resistance thermometer: Pt100 or JPt100 Infrared temperature sensor (ES1B): 10 to 70°C, 60 to 120°C, 115 to 165°C, or 140 to 260°C |
| Control output 1 | Linear current output |
| Control output 2 | None |
| Setting method | Digital setting using front panel keys |
| Indication method | 11-segment digital display and individual indicators Character height: PV: 15.2 mm, SV: 7.1 mm |
| Insulation resistance | 20 MΩ min. (at 500 VDC) |
| Dielectric strength | 3,000 VAC, 50/60 Hz for 1 min between terminals of different charge |
| Vibration resistance | Malfunction 10 to 55 Hz, 20 m/s2 for 10 min each in X, Y, and Z directions Resistance 10 to 55 Hz, 20 m/s2 for 2 hrs each in X, Y, and Z directions |
| Shock resistance | Malfunction 100 m/s2, 3 times each in X, Y, and Z directions Resistance 300 m/s2, 3 times each in X, Y, and Z directions |
| Ambient temperature (Operating) | -10 to 55°C (with no condensation or icing) |
| Ambient temperature (Storage) | -25 to 65°C (with no condensation or icing) |
| Ambient humidity (Operating) | 25 to 85 % |
| Degree of protection | Front panel: IP66, Rear case: IP20, Terminals: IP00 |
| Terminal type | Plug-in |
| Weight | Approx. 120 g, Mounting Adapter: Approx. 10 g |
The Omron E5CC-CX2AUM-000 is developed for industrial applications that require stable and responsive temperature regulation. Engineers selecting a Digital Temperature Controller typically consider this model for its compact structure, precise PID control capability, and reliable thermal response. Its panel-friendly DIN size supports integration into heating systems, process machinery, and industrial control cabinets where space efficiency is important.
This Omron PID Controller supports accurate temperature handling across applications such as packaging equipment, furnaces, heaters, and process automation systems. The controller maintains stable operation through ON/OFF and 2-PID control methods while supporting smooth monitoring through its digital display structure. Its plug-in wiring configuration simplifies installation and maintenance in continuous industrial environments.
Within the E5CC control platform, the E5CC-CX2AUM-000 configuration is recognized for stable process control and dependable electrical performance. Engineers working with temperature automation systems often evaluate this controller for its compatibility, control accuracy, and long-term operational stability. This relationship between model, control method, and industrial application makes the Omron E5CC-CX2AUM-000 a practical solution for industrial temperature management.
