In most procurement cycles, E3Z-LS88 is considered with Omron SMPS 24V 10A, E3Z D61 2M and Omron Sensors, giving decision-makers confidence that theyβve chosen the most dependable component.
Omron E3Z-LS88 Photoelectric Sensor
The Omron E3Z-LS88 Photoelectric Sensor offers Distance-settable, 2 to 80 mm (BGS setting) Sensing distance, PNP Output, M8 connector, Red LED (650 nm), 12 to 24 VDC Power supply voltage, Light-ON/Dark-ON mode. Manufactured by Omron under the Omron Photoelectric Sensors category, this model belongs to the Omron E3Z Series.
| Brand | Omron |
| Product Type | Photoelectric Sensor |
| Model Number | E3Z-LS88 |
Omron E3Z-LS88 Photoelectric Sensor β Technical Specifications
| Specification | Value |
|---|---|
| Sensing Method | Distance-settable |
| Sensing Distance | 2 to 80 mm (BGS setting) |
| Light Source | Red LED (650 nm) |
| Power Supply Voltage | 12 to 24 VDC |
| Output configuration | PNP |
| Connection Method | M8 connector |
| Current Consumption | 30 mA max. |
| Operation Mode | Light-ON/Dark-ON |
| Response Time | Operate or reset: 1 ms max |
| Sensitivity Adjustment | One-turn adjuster |
| Ambient Illumination | Incandescent lamp: 3,000 lx max.; Sunlight: 10,000 lx max. |
| Ambient Temperature Range | Operating: β25 to 55Β°C, Storage: β40 to 70Β°C (with no icing or condensation) |
| Ambient Humidity Range | Operating: 35% to 85%, Storage: 35% to 95% (with no condensation) |
| Insulation Resistance | 20 MΞ© min. at 500 VDC |
| Dielectric Strength | 1,000 VAC at 50/60 Hz for 1 minute |
| Vibration Resistance | Destruction: 10 to 55 Hz, 1.5-mm double amplitude for 2 hours each in X, Y, and Z directions |
| Shock Resistance | Destruction: 500 m/s2 for 3 times each in X, Y, and Z directions |
| Protection Circuits | Reversed power supply polarity protection, Output short-circuit protection, Mutual interference prevention |
| Degree of Protection | IP67 (IEC 60529) |
| Material | PBT (polybutylene terephthalate) |
| Weight | Approx. 20 g |
Omron continues to lead the automation industry with compact, durable, and high-performance sensors such as the Omron E3Z-LS88. Designed to meet the demanding needs of industrial automation, this Omron Distance-settable Photoelectric Sensor offers enhanced background suppression (BGS), providing engineers with reliable detection even in reflective or space-constrained environments. Known for consistency and innovation, Omronβs E3Z series supports accuracy without compromise, and the E3Z LS88 model is a standout performer in its class.
The Omron E3Z-LS88 operates on 12 to 24 VDC and features a Red LED light source at 650 nm. It supports a sensing range from 2 to 80 mm using BGS and delivers a fast 1 ms response time. With PNP output, one-turn sensitivity adjuster, and a convenient M8 connector, this sensor is ready for easy integration. It includes protection circuits against reverse polarity and short circuits, ensuring long-term durability. The enclosure is made from PBT and rated IP67 for reliable operation in harsh conditions.
The E3Z LS88 is ideal for packaging lines, printing machines, and robotics where precise distance detection is required. Its small form factor and IP67 protection allow installation in tight or exposed areas without sacrificing performance. Whether used in conveyor part detection or label presence sensing, the Omron E3Z-LS88 remains a dependable Omron Distance-settable Photoelectric Sensor across industries.
