Omron E2Q6-N30MF3-H Proximity Sensor
The Omron E2Q6-N30MF3-H Proximity Sensor offers Rectangular, Unshielded, 30 mm Sensing distance, PNP NO + NC, Terminal block , 10 to 30 VDC Power supply voltage, IP67 Protection. Manufactured by Omron under the Omron Proximity Sensors category, this model belongs to the Omron E2Q6 Series.
| Brand | Omron |
| Product | Proximity Sensors |
| Model Number | E2Q6-N30MF3-H |
Omron E2Q6-N30MF3-H Proximity Sensor - Technical Specifications
| Specification | Value |
|---|---|
| Sensor | Rectangular |
| Sensing Distance | 30 mm |
| Setting Distance | 0 to 24 mm |
| Output Configuration | PNP |
| Operation Mode | NO + NC |
| Connection | Terminal block |
| Differential Travel | 15% max. of sensing distance |
| Detectable Object | Ferrous metal |
| Standard Sensing Object | Iron, 90 Γ 90 Γ 1 mm |
| Response Frequency | 100 Hz |
| Current Consumption | 20 mA max. |
| Control Output Load Current | 200 mA max. |
| Indicator | Power indicator (green), detection indicator (yellow) |
| Protection Circuit | Power supply reverse polarity protection, output reverse polarity protection, and load short-circuit protection |
| Ambient Temperature Range | Operating and storage: β25 to 70Β°C (with no icing or condensation) |
| Ambient Humidity Range | Operating and storage: 35% to 95% (with no condensation) |
| Material | Polyamide (PA) |
| Degree Of Protection | IP67 |
| Weight | Approx. 250 g/approx. 230 g |
The Omron E2Q6-N30MF3-H is typically considered together with other sensors in the E2Q6 Rectangular Proximity Sensor family because they follow similar mounting patterns, supply ranges, and adjustment behaviour. In practice, engineers often review related models such as Omron E2K-X15ME1 2M (Capacitive, 15 mm sensing, Unshielded, DC 3-wire, NPN, NO, Pre-wired 2 M Cable), Omron TL-N20ME2 2M (Rectangular, 20 mm sensing, Unshielded, DC 3-wire, NPN, NC, Pre-wired 2 M Cable), and Omron TL-W5MC1 5M (Flat Inductive, 5 mm sensing, Unshielded, DC 3-wire NPN, NO, Pre-wired 5 M Cable) when selecting the most suitable variant for a tank, chute, conveyor, or compact fixture location. Comparing type, usable sensing distance, mounting style, output configuration, switching mode, and connection method helps match each sensor to the available mechanical space and wiring layout. The E2Q6-N30MF3-H fits naturally into panels, machine frames, dosing systems, and process equipment where a robust Omron Rectangular Proximity Sensor is required for repeatable switching in industrial environments.
