Omron E2EH-X7D1-T 5M Proximity Sensor
The Omron E2EH-X7D1-T 5M Proximity Sensor offers Inductive, M18, Shielded, 7 mm Sensing distance, DC 2-wire NO, Pre-wired 5 M Cable, 12 to 24 VDC Power supply voltage. Manufactured by Omron under the Omron Proximity Sensors category, this model belongs to the Omron E2EH Series.
| Brand | Omron |
| Product Type | Proximity Sensor |
| Model Number | E2EH-X7D1-T 5M |
Omron E2EH-X7D1-T 5M Proximity Sensor - Technical Specifications
| Specification | Value |
|---|---|
| Size | M18 |
| Mounting type | Shielded |
| Sensing Distance | 7 mm |
| Setting Distance | 0 to 5.6 mm |
| Output configuration | DC 2-wire |
| Operation Mode | NO |
| Connection Method | Pre-wired 5 M Cable |
| Detectable Object | Ferrous metal |
| Standard Sensing Object | Iron 21 Γ 21 Γ 1 mm |
| Response Frequency | 300 Hz |
| Power Supply Voltage | 12 to 24 VDC |
| Protection Circuit | Surge suppressor, Load short-circuit protection |
| Ambient Temperature Range | Operating: 0 to 100Β°C Storage: β25 to 70Β° (with no icing or condensation) |
| Degree of Protection | IEC IP67, DIN 40050-9 IP69K |
| Control Output | 3 to 100 mA |
| Indicators | Operation indicator (red), Setting indicator (yellow) |
| Materials | Stainless steel (SUS316L, PBT, Heat-resistant PVC cable . |
| Weight | Approx. 145 g |
The Omron E2EH-X7D1-T 5M is often compared with other models in the E2EH Proximity Sensor group due to shared installation characteristics and consistent sensing behavior. Engineers frequently evaluate Omron E2EH-X12B1 2M (M30, 12 mm sensing, DC 3-wire PNP, 2 M Cable), Omron E2EH-X12C2 2M (M30, 12 mm sensing, DC 3-wire NPN, NC, 2 M Cable), and Omron E2EH-X3B1 5M (M12, 3 mm sensing, DC 3-wire PNP) when selecting suitable alternatives. This ensures compatibility when matching size, sensing distance, wiring style, output logic, or connector format. The E2EH-X7D1-T 5M integrates smoothly into machinery, fixtures, conveyors, and automation systems requiring dependable detection from an Omron High-Temperature Proximity Sensor.
