Omron E2EF-QX2D1-M1TGJ 0.3M Proximity Sensor
Omron E2EF-QX2D1-M1TGJ 0.3M provides 2 mm sensing through an M8 shielded body with a 0 to 1.4 mm setting range. DC 2-wire normally open operation is connected through an M12 pre-wired Smartclick connector with a 0.3 m cable. The sensor operates from 10 to 30 VDC. The E2EF-QX2D1-M1TGJ 0.3M forms part of the E2EF Series, while comparable compact stainless formats appear in the M8 2-wire proximity sensor range across the Omron Sensing Range.
| Brand | Omron |
| Product | Proximity Sensors |
| Model Number | E2EF-QX2D1-M1TGJ 0.3M |
Omron E2EF-QX2D1-M1TGJ 0.3M Proximity Sensor - Technical Specifications
| Specification | Value |
|---|---|
| Sensor | Inductive |
| Size | M8 |
| Mounting type | Shielded |
| Sensing Distance | 2mm |
| Setting Distance | 0 to 1.4 mm |
| Output configuration | DC 2-Wire |
| Operation Mode | NO |
| Connection Method | M12 Pre-wired Smartclick Connector 0.3 M Cable |
| Detectable Object | Ferrous metal |
| Standard Sensing Object | 2mm |
| Response Frequency | 0 to 1.4 mm |
| Power Supply Voltage | 10 to 30 VDC |
| Protection Circuit | Surge suppressor, Load short-circuit protection |
| Ambient Temperature Range | Operating : −10 to 70°C, Storage : −25 to 70°C (with no icing or condensation) |
| Degree of Protection | IEC 60529 IP67 |
| Control Output | 3 to 100 mA |
| Indicators | Operation indicator (red LED), Setting indicator (green LED) |
| Materials | Stainless steel (SUS303), Zinc-plated iron, PVC (flame retardant). |
| Weight | Approx. 65 g |
The Omron E2EF-QX2D1-M1TGJ 0.3M Proximity Sensor uses an M8 shielded body with a 2 mm sensing distance and a setting range from 0 to 1.4 mm. Its DC 2-wire output operates as normally open through an M12 pre-wired Smartclick connector with a 0.3 m cable. Supply voltage is 10 to 30 VDC, while load current ranges from 3 to 100 mA. Surge suppression and load short-circuit protection are included in the electrical specification. A red LED provides operation indication and a green LED provides setting indication. Stainless steel, zinc-plated iron, and flame-retardant PVC are listed among the materials. The M8 body keeps the sensing format compact while the Smartclick connection provides short detachable wiring.
Where an Omron M8 proximity sensor requires shielded 2 mm sensing, two-wire NO switching, and short Smartclick wiring, the corresponding model is the E2EF-QX2D1-M1TGJ. Operating temperature extends from -10 to 70°C and storage from -25 to 70°C, together with IEC 60529 IP67. The specification also applies to Omron 2-wire proximity sensor, Omron 2 mm proximity sensor, Omron shielded proximity sensor, and Omron Smartclick proximity sensor requirements. Its compact M8 body provides a smaller threaded option than M12, M18, and M30 E2EF versions while retaining two-wire operation. For the same E2EF QX M8 shielded 2 mm two-wire NO format with a pre-wired 2 m cable, see E2EF-QX2D1 2M.
