Omron E2E-X7D1S-M1: M18 7mm Sensing Range in Chennai
The technical specifications for the Omron M18 7mm Sensing Range E2E-X7D1S-M1:
- Sensor Head Diameter: M18
- Installation: Flush/Shielded
- Sensing Distance: 7 mm
- Connection Method: M12 Connector Models
- Switching: NO
- Output Configuration: DC 2 Wire
- Response Frequency: 1 kHz
- Power Supply Voltage: 12 to 24 VDC
Omron M18 7mm Sensing Range E2E-X7D1S-M1 Technical Specification:
| Sensor Head (Dia) | M18 |
| Installation | Flush | Shielded |
| Sensing Distance | 7 mm |
| Connection Method | M12 Connector Models |
| Switching | NO |
| Output Configuration | DC 2 Wire (No Self-diagnostic Output) |
| Differential travel | 15% max. of sensing distance |
| Detectable object | Ferrous metal (The sensing distance decreases with non-ferrous metal.) |
| Standard sensing object | Iron, 12 × 12 × 1 mm |
| Response frequency | 1 kHz |
| Power supply voltage | 12 to 24 VDC, ripple (p-p): 10% max. (10 to 30 VDC) |
| Leakage current | 0.8 mA max |
| Indicator | Operation indicator (red) and setting indicator (green) |
| Protection circuit | Surge suppressor, Load short-circuit protection (for control and diagnostic output) |
| Ambient air temperature | Operating: −25 to 70°C, Storage: −40 to 85°C (with no icing or condensation) |
| Ambient humidity | Operating/storage: 35% to 95% (with no condensation) |
| Voltage influence | ±1% max. of sensing distance at the rated voltage in the rated voltage ±15% range |
| Degree of protection | IEC 60529 IP67, in-house standards: oil-resistant |
| Material Case | Stainless steel (SUS303) |
| Material Sensing surface | PBT |
Are you looking for the Omron E2E-X7D1S-M1 Sensor in Chennai? You’re in the right place. This sensor has an M18 7mm Sensing Range, flush and shielded installation, M12 connector models, Normally Open (NO) switching, DC 2 Wire output, 1 kHz response frequency, and operates on 12-24 VDC power. It has a max 15% differential travel and is designed for detecting ferrous metal, optimally sensing iron-sized 12 × 12 × 1 mm. The case is made of stainless steel (SUS303). Find the best prices at IndMALL Automation.
