Omron E2E-X18MY2 2M Proximity Sensor
Omron E2E-X18MY2 2M is an M30 unshielded inductive proximity sensor with an 18 mm sensing distance and 0 to 14 mm setting distance. It provides AC 2-wire NC switching through an oil-resistant PVC pre-wired 2 m cable and operates from 24 to 240 VAC. Ferrous metal is the specified detectable object, with an iron 54 × 54 × 1 mm standard sensing object. Response frequency is 25 Hz, while control output is rated from 5 to 300 mA. A red LED indicates operation, and surge suppression is specified for the electrical circuit. The E2E-X18MY2 2M is included among AC 2-wire proximity sensors from Omron factory automation sensing.
| Brand | Omron |
| Product | Proximity Sensors |
| Model Number | E2E-X18MY2 2M |
Omron E2E-X18MY2 2M Proximity Sensor - Technical Specifications
| Specification | Value |
|---|---|
| Sensor | Inductive |
| Housing Shape | Cylindrical |
| Size | M30 |
| Mounting type | Unshielded |
| Sensing Distance | 18 mm |
| Setting Distance | 0 to 14 mm |
| Output configuration | AC 2-Wire |
| Operation Mode | NC |
| Connection Method | Pre-wired 2 M Cable |
| Cable specifications | PVC (Oil-resistant) |
| Detectable Object | Ferrous metal |
| Standard Sensing Object | Iron, 54 × 54 × 1 mm |
| Response Frequency | 25 Hz |
| Power Supply Voltage | 24 to 240 VAC |
| Protection Circuit | Surge suppressor |
| Ambient Temperature Range | Operating/Storage: −40 to 85°C (with no icing or condensation) |
| Degree of Protection | IEC 60529 IP67, in-house standards: oil-resistant |
| Control Output | 5 to 300 mA |
| Indicators | Operation indicator (red) |
| Materials | Nickel-plated brass, Polybutylene terephthalat (PBT), Nickel-plated brass, Zinc-plated iron, Vinyl chloride (PVC). |
| Weight | Approx. 175 g |
The Omron E2E-X18MY2 2M Proximity Sensor uses a cylindrical M30 unshielded inductive sensing body with an 18 mm sensing distance and a 0 to 14 mm setting distance. It provides AC 2-wire NC operation through an oil-resistant PVC pre-wired 2 m cable and operates from 24 to 240 VAC. Ferrous metal is the specified detectable object, paired with an iron 54 × 54 × 1 mm standard sensing object. Response frequency is 25 Hz, while control output is rated from 5 to 300 mA. A red operation indicator is provided for switching status, and surge suppression is specified for the electrical circuit.
Operating and storage conditions for the E2E-X18MY2 extend from -40 to 85°C without icing or condensation. IEC 60529 IP67 and an in-house oil-resistant rating are specified. Nickel-plated brass, PBT, zinc-plated iron, and PVC are listed among the construction materials. The unshielded M30 sensing format combines an 18 mm detection range with AC 2-wire NC switching and direct cable connection. The oil-resistant PVC cable supports fixed industrial wiring, while ferrous metal remains the specified sensing target. For another E2E sensor in the supplied comparison set using NPN switching and a compact 3 mm diameter sensing body, see E2E-C03SR8-WC-C2 5M.
