Omron E2E-X2MY1 2M Proximity Sensor
Omron E2E-X2MY1 2M is a cylindrical M8 unshielded inductive proximity sensor with a 2 mm sensing distance and 0 to 1.6 mm setting distance. It uses AC 2-wire NO switching through an oil-resistant PVC pre-wired 2 m cable and operates from 24 to 240 VAC. Ferrous metal is the specified detectable object, with an iron 12 × 12 × 1 mm standard sensing object. Response frequency is 25 Hz, while control output is rated from 5 to 100 mA. A red LED provides operation indication, and surge suppression is specified. The E2E-X2MY1 2M is listed among M8 AC 2-wire proximity sensors from Omron industrial sensing products.
| Brand | Omron |
| Product | Proximity Sensors |
| Model Number | E2E-X2MY1 2M |
Omron E2E-X2MY1 2M Proximity Sensor - Technical Specifications
| Specification | Value |
|---|---|
| Sensor | Inductive |
| Housing Shape | Cylindrical |
| Size | M8 |
| Mounting type | Unshielded |
| Sensing Distance | 2 mm |
| Setting Distance | 0 to 1.6 mm |
| Output configuration | AC 2-Wire |
| Operation Mode | NO |
| Connection Method | Pre-wired 2 M Cable |
| Cable specifications | PVC (Oil-resistant) |
| Detectable Object | Ferrous metal |
| Standard Sensing Object | Iron, 12 × 12 × 1 mm |
| Response Frequency | 25 Hz |
| Power Supply Voltage | 24 to 240 VAC |
| Protection Circuit | Surge suppressor |
| Ambient Temperature Range | Operating/Storage: −25 to 70°C (with no icing or condensation) |
| Degree of Protection | IEC 60529 IP67, in-house standards: oil-resistant |
| Control Output | 5 to 100 mA |
| Indicators | Operation indicator (red) |
| Materials | Stainless steel (SUS303), PBT, Nickel-plated brass, Zinc-plated iron. |
| Weight | Approx. 60 g |
The Omron E2E-X2MY1 2M Proximity Sensor uses a cylindrical M8 unshielded inductive sensing body with a 2 mm sensing distance and a 0 to 1.6 mm setting distance. It provides AC 2-wire NO switching through an oil-resistant PVC pre-wired 2 m cable and operates from 24 to 240 VAC. Ferrous metal is the specified detectable object, with an iron 12 × 12 × 1 mm standard sensing object. Response frequency is 25 Hz, while control output is rated from 5 to 100 mA. A red operation indicator provides switching status, while surge suppression is specified for the electrical circuit. The compact M8 format supports restricted industrial mounting positions.
Operating and storage conditions for the E2E-X2MY1 cover -25 to 70°C without icing or condensation. IEC 60529 IP67 and an in-house oil-resistant rating are listed. SUS303 stainless steel, PBT, nickel-plated brass, and zinc-plated iron are included among the construction materials. The unshielded M8 sensing format combines the stated 2 mm range with AC 2-wire NO switching and fixed cable connection. The oil-resistant PVC cable supports direct machine wiring, while ferrous metal remains the specified detection target. The 24 to 240 VAC supply range supports the stated AC configuration. For another E2E model with NPN NC switching, an M12 body, and an 8 mm sensing distance, see E2E-X8MC212-M1.
