Omron E2E-S04N02-WC-C2 5M Small-diameter Proximity Sensor
The Omron E2E-S04N02-WC-C2 5M Small-diameter Proximity Sensor offers Inductive, M4, Unshielded, 2 mm Sensing distance, PVC (oil-resistant), Pre-wired 5 M Cable, DC 3-wire NPN NC Output, 10 to 30 VDC Power supply voltage. Manufactured by Omron under the Omron Proximity Sensors category, this model belongs to the Omron E2E Small Diameter Series.
| Brand | Omron |
| Product Type | Proximity Sensor |
| Model Number | E2E-S04N02-WC-C2 5M |
Omron E2E-S04N02-WC-C2 5M Proximity Sensor - Technical Specifications
| Specification | Value |
|---|---|
| Sensing head size | M4 |
| Mounting type | Unshielded |
| Sensing distance | 2 mm |
| Setting distance | 0 to 1.4 mm |
| Response frequency | 3.5 kHz |
| Sensing object | Ferrous metal (Sensitivity lowers with non-ferrous metals.) |
| Standard sensing object | Iron, 6 Γ 6 Γ 1 mm |
| Connection method | Pre-wired 5 M Cable |
| Cable specifications | PVC (oil-resistant) |
| Differential distance | 15% max. of sensing distance |
| Power supply voltage | 10 to 30 VDC |
| Current consumption | 10 mA max. |
| Control output (Switching capacity) | 50 mA max. |
| Control output (Residual voltage) | 2 V max. |
| Indicator | Operation indicator (yellow) |
| Control output (Output type) | NPN open collector |
| Protective circuit | Output short-cut protection Output reverse polarity protection Power supply reverse polarity protection Surge suppressor |
| Operation mode | NC |
| Wire color / pin arrangement | Brown: +V Black: Output Blue: 0 V |
| Ambient temperature (Operating/Storage) | -25 to 70 β/-25 to 70 β |
| Ambient humidity (Operating/Storage) | 35 to 95 %/35 to 95 % |
| Temperature influence | Β±15% max. of sensing distance at 23 β in the temperature range of -25 to 70 β |
| Voltage influence | Β±2.5% max. of sensing distance at rated voltage in the rated voltage Β±15% range |
| Insulation resistance | Between charged parts and the case: 50 MΞ© min. at 500 VDC |
| Dielectric strength | Between charged parts and the case: 500 VAC 50/60 Hz 1 min |
| Vibration resistance | Destruction: 10 to 55 Hz, 1.5 mm double amplitude each in X, Y, and Z directions for 2 h |
| Shock resistance | Destruction: 500 m/s2 10 times each in X, Y, and Z directions |
| Degree of protection | IEC: IP67 Company standard: Oil-proof |
| Material | Case: SUS303 (EN1.4305) Sensing surface: Heat-resistant ABS resin Cable: PVC |
| Weight | Approx. 30 g |
The Omron E2E-S04N02-WC-C2 5M Proximity Sensor is often used alongside other small-diameter inductive sensors in the E2E series, as these models share similar installation patterns and stable detection behavior. Engineers comparing options in this range frequently look at alternatives such as Omron E2E-C03N02-CJ-B2 0.3M (head size 3 dia, Pre-wired M8 connector, 0.3 M Cable), Omron E2E-C03N02-WC-B1 2M (head size 3 dia, NO, Pre-wired 2 M Cable), and Omron E2E-C03N02-WC-B1 5M (head size 3 dia, NO switching mode). Using related sensors from the same family helps maintain consistent wiring layouts, predictable sensing performance, and easier panel design. The E2E-S04N02-WC-C2 5M fits naturally into applications requiring compact sensing heads, short detection ranges, and stable switching in tight industrial spaces, making it suitable for machine builders standardizing on Omronβs small-diameter proximity line.
