Omron E2CY-SD11 2M Proximity Sensor
Omron E2CY-SD11 2M is a separate-amplifier proximity sensor unit with a DC 3-wire NPN output supporting NO/NC operation and a 12 to 24 VDC supply. Current consumption is specified as 1,080 mW max., equivalent to 45 mA max. at 24 VDC, while the control output is rated at 100 mA max. with a 1 V max. residual voltage. An orange operation indicator provides output status. Power-supply reverse-polarity protection and output short-circuit protection are listed. Operating temperature is -10 to 55°C, while storage extends from -25 to 70°C. PBT, polycarbonate, and zinc-plated iron are specified among the materials. The E2CY-SD11 2M is included under Proximity sensor products from Omron industrial sensing.
| Brand | Omron |
| Product | Proximity Sensors |
| Model Number | E2CY-SD11 2M |
Omron E2CY-SD11 2M Proximity Sensor - Technical Specifications
| Specification | Value |
|---|---|
| Sensor | Separate Amplifier |
| Output Configuration | DC 3-wire NPN |
| Operation Mode | NO/NC |
| Current Consumption | 1,080 mW max. (45 mA max. at 24 VDC) |
| Control Output Load Current | 100 mA max., 1 V max. |
| Indicator | Operation indicator (orange) |
| Protection Circuit | Power supply reverse polarity protection and output short-circuit protection |
| Ambient Temperature Range | Operating: −10 to 55°C, Storage: −25 to 70°C (with no icing or condensation) |
| Ambient Humidity Range | Operating and storage: 35% to 85% (with no condensation) |
| Material | PBT, Polycarbonate, Zinc-plated iron. |
| Degree Of Protection | IP50 |
| Weight | Approx. 100 g |
The Omron E2CY-SD11 2M Proximity Sensor is a separate-amplifier unit with a DC 3-wire NPN output supporting NO/NC operation and a 12 to 24 VDC supply. Power consumption is specified as 1,080 mW max., equivalent to 45 mA max. at 24 VDC. The control output is rated at 100 mA max. with a residual voltage of 1 V max. An orange operation indicator provides output status. Power-supply reverse-polarity protection and output short-circuit protection are included. The supplied data identifies the unit as part of a separate-amplifier proximity sensing configuration rather than providing a sensing distance for the amplifier itself.
Operating temperature for the E2CY-SD11 is -10 to 55°C, while storage extends from -25 to 70°C without icing or condensation. Operating and storage humidity is 35% to 85%. PBT, polycarbonate, and zinc-plated iron are listed among the construction materials, and IP50 is the specified protection level. The source does not provide a separate sensing-head size or sensing distance for this amplifier row, so those values are not added. For another pre-wired Omron sensing product using a DC 3-wire circuit and NO operation, see E2K-X8MF1 2M.
