E2B-S08KS02-WP-B1 2M : Omron PNP NO Sensor in Chennai
Technical specifications of Omron PNP NO Sensor E2B-S08KS02-WP-B1:
- Sensor Head diameter: M8
- Installation: Flush | shielded
- Sensing Distance: 2mm
- Body Length: Short (42mm)
- Output Configuration: PNP
- Switching: NO
- Connection: Pre-Wired, 2M Length
- Power Supply Voltage Range: 10 to 30 V.
Omron PNP NO Sensor E2B-S08KS02-WP-B1 2M Technical Specifications:
| Sensor Head (Dia) | M8 |
| Installation | Flush | Shield |
| Sensing Distance | 2mm |
| Body Length | Short (42 mm) |
| Output Configuration | PNP |
| Switching | NO (Normally Open) |
| Connection | Pre Wired Cable, 2M Length |
| Differential travel | 10% max. of sensing distance |
| Detectable object | Ferrous metal (The sensing distance decreases with non-ferrous metal.) |
| Standard sensing object | 8 × 8 × 1 mm |
| Response frequency | 1,500 Hz |
| Power supply voltage | 10 to 30 VDC. (including 10% ripple (p-p)) |
| Current consumption | 10 mA max |
| Indicator | Operation indicator (Yellow LED) |
| Protection circuit | Output reverse polarity protection, Power source circuit reverse polarity protection, Surge suppressor, Short-circuit protection |
| Ambient air temperature | Operation and storage: -25 to 70ºC |
| Ambient humidity | Operation and Storage: 35 to 95% |
| Voltage influence | ±1% max. of sensing distance in 24 V ±15% |
| Standard and listings | (1) IP67 (IEC60529) (2) EMC (EN60947-5-2) |
| Material Case | Stainless steel (1.4305 (W.-No.), SUS 303 (AISI), 2346 (SS).) |
| Material Sensing surface | PBT |
| Material Cable | The standard cable is 4 mm dia. PVC |
| Material Clamping nut | Brass-nickel plated |
The Omron PNP NO Sensor, model E2B-S08KS02-WP-B1 2M, available at IndMALL a Chennai based company. Features a compact M8 sensor head diameter and a short body length of just 42mm. Designed for flush installation and shielded for enhanced durability, this sensor boasts a precise sensing distance of 2mm. Its output configuration is PNP with a normally open (NO) switching mechanism, ensuring reliable and efficient operation. Additionally, it includes a pre-wired connection with a 2-meter length for ease of installation. The power supply voltage range for this sensor is versatile, accommodating 10 to 30 volts, making it an ideal choice for various industrial applications.
