Omron E2B-M18KN16-WP-B1 2M : M18 Proximity Sensor in Chennai
Technical specifications of Omron E2B-M18KN16-WP-B1 2M M18 Proximity Sensor:
Sensor head diameter: M18 (18mm)
Installation type: Non-Flush/Unshielded
Sensing distance: 16mm
Body length: Short (56mm)
Output configuration: PNP
Switching type: NO (Normally Open)
Connection: Pre-Wired with a 2M cable
Response frequency: 500Hz
Omron E2B-M18KN16-WP-B1 2M M18 Proximity Sensor Technical Specification:
| Sensor Head (Dia) | M18 (18mm) |
| Installation | Non-Flush | Unshielded |
| Sensing Distance | 16 mm |
| Body Length | Short (56 mm) |
| Output Configuration | PNP |
| Switching | NO |
| Connection | Pre-Wired, 2M Length |
| Differential travel | 10% max. of sensing distance |
| Detectable object | Ferrous metal (The sensing distance decreases with non-ferrous metal.) |
| Standard sensing object | 24 × 24 × 1 mm |
| Response frequency | 500 Hz |
| Power supply voltage | 10 to 30 VDC. (including 10% ripple (p-p)) |
| Current consumption | 10 mA max |
| Indicator | Operation indicator (Yellow LED) |
| Protection circuit | Output reverse polarity protection, Power source circuit reverse polarity protection, Surge suppressor, Short-circuit protection |
| Ambient air temperature | Operation and storage: -25 to 70ºC |
| Ambient humidity | Operation and Storage: 35 to 95% |
| Voltage influence | ±1% max. of sensing distance in 24 V ±15% |
| Standard and listings | (1) IP67 (IEC60529) (2) EMC (EN60947-5-2) |
| Material Case | Brass-nickel plated |
| Material Sensing surface | PBT |
| Material Cable | The standard cable is 4 mm dia. PVC |
| Material Clamping nut | Brass-nickel plated |
The M18 Proximity Sensor, specifically the Omron E2B-M18KN16-WP-B1 2M, is a high-performance sensor with a sensor head diameter of M18 (18mm) and a body length of 56mm, making it compact and efficient for various applications. This non-flush/unshielded sensor boasts a sensing distance of 16mm and is equipped with a PNP output configuration and a NO (Normally Open) switching type, ensuring reliable detection. IndMALL in Chennai, offers this sensor complete with a pre-wired 2M cable, a response frequency of 500Hz, and a power supply voltage range of 10-30VDC, making it a versatile choice for industrial sensing needs.
