Omron D4C-1360 Limit Switch
Omron D4C-1360 is a D4C Series limit switch with a center roller lever for machine position and travel detection. The centered roller arrangement suits moving parts that sweep across the actuator, providing rolling mechanical contact for repeated position sensing. This model supports standard loads rated at 5 A at 250 VAC and 4 A at 30 VDC. A 5 m VCTF oil-resistant cable provides extended routing from the sensing point and simplifies installation where the connection point is located away from the switch. The D4C-1360 belongs to the D4C Series within the center roller lever switch range from Omron industrial control products for machine travel, position, and end-point sensing.
| Brand | Omron |
| Product | Limit Switch |
| Model Number | D4C-1360 |
Omron D4C-1360 Limit Switch – Technical Specifications
| Specification | Value |
|---|---|
| Electrical Ratings | 5 A at 250 VAC, 4 A at 30 VDC |
| Load | Standard load |
| Cable Specifications | VCTF oil- resistant cable |
| Cable Length | 5 m |
| Actuator | Center roller lever |
The Omron D4C-1360 Limit Switch uses a center roller lever for machine position and travel detection. The centered roller arrangement provides rolling mechanical contact with moving parts that sweep across the actuator, making it useful where direct plunger actuation is not preferred. The supplied product information specifies a standard-load rating of 5 A at 250 VAC and 4 A at 30 VDC. A 5 m VCTF oil-resistant cable provides extended routing from the sensing point and simplifies prewired installation where the switch is mounted away from the control connection.
The D4C-1360 is primarily distinguished by its center roller lever and 5 m cable configuration. The roller lever supports repeated contact with cams, slides, or moving machine components, while the oil-resistant VCTF cable can be routed around equipment where lubricants are present. The source does not provide the wider environmental, durability, or contact-resistance specifications shown for some other D4C models in the same file, so those values are not added here. For a related D4C model using a high-sensitivity roller lever with the same 5 m oil-resistant cable and standard-load rating, see the D4C-1324 model.
