Multispan TC-49-A2-N2-W: Temperature Controller
Technical Specifications of Multispan Temperature Controller TC-49-A2-N2-W:
| Spec | Value |
|---|
| Input | Pt-100 |
| Output | Relay || SSR |
| Display Color | White |
| Auxillary Supply | 100-270V AC |
| Size | 48x48x70(HxWxD)mm |
Multispan Temperature Controller TC-49-A2-N2-W Technical Specifications
| Specification | Value |
|---|
| Input | Pt-100 |
| Output | Relay || SSR |
| Auxillary Supply | 100-270V AC |
| Display Color | White |
| Size | 48x48x70(HxWxD)mm |
| Supply Voltage | 100 to 270V AC, 50-60Hz |
| Power Consumption (VA Rating) | 4VA @ 230V AC MAX |
| Operating Temp. | 0°C to 55°C |
| Relative Humidity | Upto 95% RH |
| Protection Level | IP-65 (Front side) As per IS/IEC 60529 : 2001 |
| Input Range | J : 0 to 600°C
K : 0 to 999°C |
| Resolution | 1°C |
| Indication Accuracy | ±1% of FSD ± 1°C |
| Display | 3-Digit, 7-Segment, 0.8” RED |
| Keys | SET, INC, DEC |
| Panel Cutout (mm) | 45 (H) x 45 (W) |
| Heating | 1. PID control with Auto-Tuning
2. ON-OFF Control |
| Relay | 1 Nos |
| Relay Type | 1C/O (NO-C-NC) |
| Rating | 10A, 230V AC / 28V DC |
| SSR Output Signal | 12V DC, 30mA DC |
| Analog Output | 4 to 20mA DC/0 to 10V DC (Factory Set) |
| Transmitter supply | 24V DC |
| Modbus Communication | RS-485 |
