TC-29-A2-05 - Multispan Digital Temperature Controller
Multispan TC-29-A2-05 Digital Temperature Controller supports Pt100 input, relay and SSR output, PID auto-tuning, and communication. The TC-29-A2-05 Digital Temperature Controller belongs to the TC Series and features Pt100 input, relay and SSR output, PID control with Auto-Tuning, and RS-485 Modbus communication. The Multispan controller is part of the Multispan Digital PID Temperature Controller range and is used for industrial temperature control applications.
| Brand | Multispan |
| Product Type | Temperature Controller |
| Model Number | TC-29-A2-05 |
TC-29-A2-05 Multispan Digital Temperature Controller - Technical Specifications
| Specification | Value |
|---|---|
| Input | Pt-100 |
| Output | Relay || SSR |
| Auxillary Supply | 100-270V AC |
| Display Color | Red |
| Size | 72x72x45(HxWxD)mm |
| Supply Voltage | 100 to 270V AC, 50-60Hz |
| Power Consumption (VA Rating) | 4VA @ 230V AC MAX |
| Operating Temp. | 0°C to 55°C |
| Relative Humidity | Upto 95% RH |
| Protection Level | IP-65 (Front side) As per IS/IEC 60529 : 2001 |
| Input Range | J : 0 to 600°C K : 0 to 999°C |
| Resolution | 1°C |
| Indication Accuracy | ±1% of FSD ± 1°C |
| Display | 3-Digit, 7-Segment, 0.8” RED |
| Keys | SET, INC, DEC |
| Panel Cutout (mm) | 45 (H) x 45 (W) |
| Heating | 1. PID control with Auto-Tuning 2. ON-OFF Control |
| Relay | 1 Nos |
| Relay Type | 1C/O (NO-C-NC) |
| Rating | 10A, 230V AC / 28V DC |
| SSR Output Signal | 12V DC, 30mA DC |
| Analog Output | 4 to 20mA DC/0 to 10V DC (Factory Set) |
| Transmitter supply | 24V DC |
| Modbus Communication | RS-485 |
The Multispan TC-29-A2-05 Digital Temperature Controller is part of the TC Series designed for industrial automation and process temperature management. The TC-29-A2-05 Digital Temperature Controller supports Pt100 input, relay and SSR output, PID Auto-Tuning, and RS-485 Modbus communication. The TC Series is widely used where accurate temperature monitoring, stable control performance, and dependable communication are required. Multispan temperature controllers help maintain process consistency across industrial heating and automation applications.
The Digital Temperature Controller is commonly installed in conveyors, packaging machines, assembly systems, ovens, furnaces, and industrial automation equipment. The TC Series supports PID control and ON-OFF control modes for maintaining stable process temperatures. Relay outputs, SSR outputs, analog output capability, and Modbus communication allow seamless integration with PLCs, HMIs, and supervisory systems. These functions help improve temperature regulation, process efficiency, and operational reliability across manufacturing and process industries.
Multispan TC-29-A2-05 combines temperature sensing, control, communication, and output flexibility in a compact industrial controller. As a member of the TC Series, it supports Pt100 temperature measurement, relay switching, SSR control, analog retransmission, transmitter supply, and RS-485 connectivity. Multispan controllers are widely used in industrial heating, machinery, and automation systems where dependable temperature control is essential. The TC-29-A2-05 Digital Temperature Controller provides reliable monitoring and control for a wide range of industrial temperature applications.
