TC-49-A2-N1-W - Multispan Temperature Controller
Multispan TC-49-A2-N1-W Temperature Controller supports J/K input, Relay or SSR output, PID control, and RS-485 communication. The TC-49-A2-N1-W Multispan Temperature Controller belongs to the Multispan Temperature Controller category and TC Series, featuring PID Auto-Tuning, IP65 front protection, Relay or SSR output, and RS-485 Modbus communication with 100-270V AC auxiliary supply.
| Brand | Multispan |
| Product Type | Temperature Controller |
| Model Number | TC-49-A2-N1-W |
TC-49-A2-N1-W Multispan Temperature Controller - Technical Specifications
| Specification | Value |
|---|---|
| Input | J/K |
| Output | Relay || SSR |
| Auxillary Supply | 100-270V AC |
| Display Color | White |
| Size | 48x48x70(HxWxD)mm |
| Supply Voltage | 100 to 270V AC, 50-60Hz |
| Power Consumption (VA Rating) | 4VA @ 230V AC MAX |
| Operating Temp. | 0°C to 55°C |
| Relative Humidity | Upto 95% RH |
| Protection Level | IP-65 (Front side) As per IS/IEC 60529 : 2001 |
| Input Range | J : 0 to 600°C K : 0 to 999°C |
| Resolution | 1°C |
| Indication Accuracy | ±1% of FSD ± 1°C |
| Display | 3-Digit, 7-Segment, 0.8” RED |
| Keys | SET, INC, DEC |
| Panel Cutout (mm) | 45 (H) x 45 (W) |
| Heating | 1. PID control with Auto-Tuning 2. ON-OFF Control |
| Relay | 1 Nos |
| Relay Type | 1C/O (NO-C-NC) |
| Rating | 10A, 230V AC / 28V DC |
| SSR Output Signal | 12V DC, 30mA DC |
| Analog Output | 4 to 20mA DC/0 to 10V DC (Factory Set) |
| Transmitter supply | 24V DC |
| Modbus Communication | RS-485 |
The TC-49-A2-N1-W is a Multispan Temperature Controller developed for industrial temperature monitoring and control applications. This TC Series controller supports J/K thermocouple input, Relay or SSR output options, PID Auto-Tuning functionality, and RS-485 Modbus communication. The TC-49-A2-N1-W Temperature Controller offers J/K input support, PID Auto-Tuning, RS-485 communication, and IP65 front protection. It is widely used in industrial automation environments where accurate temperature regulation and process stability are required.
The TC-49-A2-N1-W Temperature Controller is commonly installed in conveyors, packaging machines, assembly systems, process heating equipment, and industrial automation panels. PID control helps maintain stable temperature conditions, while Relay and SSR output options provide flexible control methods. RS-485 Modbus communication enables monitoring and integration with automation systems. These capabilities support consistent process performance, reduced temperature variation, and reliable operation across industrial applications.
Multispan TC-49-A2-N1-W Temperature Controller combines precise temperature measurement, control functionality, and communication features in a compact 48x48mm design. The TC-49-A2-N1-W Temperature Controller operates on 100-270V AC supply voltage and provides ±1% FSD indication accuracy. Multispan controllers are trusted in industrial temperature control systems where dependable performance, communication capability, and accurate process control are important for maintaining production efficiency and operational consistency.
