Mitsubishi FR-F840-00250-E2-60 Variable Frequency Drive
Technical Specifications of Mitsubishi Variable Frequency Drive FR-F840-00250-E2-60:
| Brand | Mitsubishi |
| Product Type | Variable Frequency Drive |
| Product | FR-F840-00250-E2-60 |
Mitsubishi Variable Frequency Drive FR-F840-00250-E2-60 Technical Specifications:
| Specification | Value |
|---|---|
| Series | FR-F800 SERIES |
| Type | FR-F800-E INVERTER |
| Minimum Rated Voltage (V) | 380 |
| Min. Permissible Voltage (V) | 323 |
| Maximum Rated Voltage (V) | 500 |
| Max. Permissible Voltage (V) | 550 |
| Current Type | AC |
| Phases | 3 |
| Frequency Range (Hz) | 0,2โ590 |
| Control Method | V/F CONTROL, SOFT-PWM/HIGH FREQUENCY PWM, PM SENSORLESS VECTOR CONTROL, MAGNETIC FLUX VECTOR CONTROL |
| Motor Type | INDUCTION MOTOR, PM MOTOR |
| Integrated EMC Filter | YES |
| Safe Torque Off (STO) | YES |
| Regenerative (4Q) | NO |
| Integrated DC Choke | NO |
| Display | FR-DU08 |
| Display Type | 5 DIGITS LED (12 SEGMENT) |
| PLC Function | YES |
| Program Memory | 6K |
| Program Memory Unit | STEPS |
| Integrated Digital Inputs | 12 |
| Digital Outputs (Transistor) | 5 |
| Digital Outputs (Relay) | 2 |
| Integrated Analogue Inputs | 3 |
| Integrated Analogue Outputs | 2 |
| IO Type of Terminal Block | SPRING CLAMP |
| Expandable | YES |
| USB | 1+1 MINI |
| Ethernet Port | 1 |
| Built-In Network | CC-LINK IE FIELD NETWORK BASIC, MELSOFT/FA, iQSS, MODBUS/TCP, SLMP, BACNET/IP |
| Leakage Current (mA) | 35(DELTA) / 2(STAR) |
| Protection Class | IP20 |
| Depth (mm) | 170 |
| Weight (kg) | 6,7 |
| Width (mm) | 220 |
| Height (mm) | 260 |
| Standby Power Consumption (W) | 20 |
| Rated Output Current LD (A) | 23 |
| Rated Motor Capacity LD (kW) | 11 |
| Power Loss LD (W) | 315 |
| Rated Output Current SLD (A) | 25 |
| Rated Motor Capacity SLD (kW) | 11 |
| Power Loss SLD (W) | 345 |
| Shipping Approvals | DNV,ABS |
The Mitsubishi FR-F840-00250-E2-60 Variable Frequency Drive is a high-performance inverter from the FR-F800 SERIES used for precise motor control in industrial automation. With a rated motor capacity of 11kW and output current of 25A, it operates on a 380โ500V 3-phase AC supply. This Mitsubishi Variable Frequency Drive supports V/F and PM Sensorless Vector Control, ensuring stable torque and efficient motor performance across variable load conditions.
The Mitsubishi FR-F840-00250-E2-60 is widely used in HVAC systems, conveyors, pumps, and process automation lines requiring efficient speed regulation. Its Ethernet communication interface with Modbus/TCP and BACnet/IP enables seamless integration with industrial networks, while the Safe Torque Off (STO) feature enhances safety during maintenance. The FR-DU08 5-digit LED display ensures easy monitoring and configuration in control panels.
The Mitsubishi FR-F840-00250-E2-60 Variable Frequency Drive combines 11kW power capacity, IP20-rated protection, and multi-network connectivity for reliable operation in demanding industrial environments. As part of Mitsubishiโs trusted FR-F800 SERIES, it delivers long-term stability, energy efficiency, and precise motor controlโmaking it ideal for industrial users across India seeking high-performance automation solutions.
