Mitsubishi FR-D720S-100SC-EC Variable Frequency Drive
The Mitsubishi FR-D720S-100SC-EC Variable Frequency Drive operates with 200–240V AC single-phase input, delivering 2.2kW motor capacity, 10A rated output current, and IP20 protection. Belonging to the Mitsubishi Variable Frequency Drive range under the Mitsubishi brand, this model is part of the FR-D700 SERIES. It supports V/F Control, Soft-PWM, and Magnetic Flux Vector Control, includes RS-485 Modbus-RTU communication, features a 4-digit LED display, and provides Safe Torque Off (STO) functionality.
| Brand/Manufacturer | Mitsubishi Electric |
| Product Type | VFD (Variable Frequency Drive) |
| Model No. | FR-D720S-100SC-EC |
Mitsubishi Variable Frequency Drive FR-D720S-100SC-EC Technical Specifications:
| Specification | Value |
|---|---|
| Series | FR-D700 SERIES |
| Type | FR-D700 COMPACT INVERTER |
| Minimum Rated Voltage (V) | 200 |
| Min. Permissible Voltage (V) | 170 |
| Maximum Rated Voltage (V) | 240 |
| Max. Permissible Voltage (V) | 264 |
| Current Type | AC |
| Phases | 1 |
| Rated Output Current ND (A) | 10 |
| Rated Motor Capacity ND (kW) | 2,2 |
| Frequency Range (Hz) | 0,2–400 |
| Control Method | V/F CONTROL, SOFT-PWM/HIGH FREQUENCY PWM , MAGNETIC FLUX VECTOR CONTROL |
| Motor Type | INDUCTION MOTOR |
| Brake Chopper ED (%) | 30 |
| Integrated EMC Filter | NO |
| Display | BUILT-IN |
| Display Type | 4 DIGITS LED |
| Integrated Digital Inputs | 5 |
| Digital Outputs (Transistor) | 1 |
| Digital Outputs (Relay) | 1 |
| Depth (mm) | 145 |
| Width (mm) | 140 |
| Height (mm) | 150 |
| Protection Class | IP20 |
| Weight (kg) | 2 |
The Mitsubishi FR-D720S-100SC-EC Variable Frequency Drive is a compact inverter from the FR-D700 SERIES designed for efficient motor control in industrial automation. With a rated motor capacity of 2.2kW and rated output current of 10A, it operates across a frequency range of 0.2–400Hz. As a Mitsubishi Variable Frequency Drive, it supports V/F and Magnetic Flux Vector Control for stable operation of induction motors in automation environments.
Used widely in conveyors, packaging equipment, and process control systems, the Mitsubishi FR-D720S-100SC-EC provides reliable speed control and consistent torque output. Its RS-485 Modbus-RTU interface ensures easy communication with PLCs, while Safe Torque Off (STO) enhances operator safety. The built-in LED display and spring-clamp terminals simplify installation and maintenance, making it ideal for space-constrained control panels.
The Mitsubishi FR-D720S-100SC-EC Variable Frequency Drive combines 2.2kW power output, IP20 protection, and advanced control modes to ensure dependable performance in Indian industrial applications. Part of Mitsubishi’s proven FR-D700 SERIES, it offers robust build quality, energy-efficient operation, and long-term reliability—suitable for continuous-duty applications in automation, manufacturing, and process industries.
