Mitsubishi FR-E740-170SC-EC Variable Frequency Drive
The Mitsubishi FR-E740-170SC-EC Variable Frequency Drive provides 7.5kW motor capacity with a 17A rated output current for industrial use. This Mitsubishi drive is part of the Mitsubishi Variable Frequency Drive family and supports magnetic flux vector control and V/F control for reliable induction motor performance. Belonging to the FR-E700 SERIES, the FR-E740-170SC-EC includes STO safety, IP20 protection, built-in LED display, digital and analogue I/O, RS-485, USB connectivity, and MODBUS-RTU networking.
| Brand/Manufacturer | Mitsubishi Electric |
| Product Type | VFD (Variable Frequency Drive) |
| Model No. | FR-E740-170SC-EC |
Mitsubishi Variable Frequency Drive FR-E740-170SC-EC Technical Specifications:
| Specification | Value |
|---|---|
| Series | FR-E700 SERIES |
| Type | FR-E700 STANDARD INVERTER |
| Minimum Rated Voltage (V) | 380 |
| Min. Permissible Voltage (V) | 325 |
| Maximum Rated Voltage (V) | 480 |
| Max. Permissible Voltage (V) | 528 |
| Current Type | AC |
| Phases | 3 |
| Rated Output Current ND (A) | 17 |
| Rated Motor Capacity ND (kW) | 7,5 |
| Control Method | MAGNETIC FLUX VECTOR CONTROL, V/F CONTROL |
| Motor Type | INDUCTION MOTOR |
| Brake Chopper ED (%) | 30 |
| Integrated EMC Filter | NO |
| Display | BUILT-IN |
| Display Type | 3 DIGITS LED |
| Integrated Digital Inputs | 6 |
| Digital Outputs (Transistor) | 2 |
| Digital Outputs (Relay) | 1 |
| Depth (mm) | 153 |
| Width (mm) | 220 |
| Height (mm) | 150 |
| Protection Class | IP20 |
| Weight (kg) | 3,2 |
The Mitsubishi FR-E740-170SC-EC Variable Frequency Drive features 17A output current, 7.5kW motor capacity, magnetic flux vector control, and IP20 protection. This Mitsubishi FR-E740-170SC-EC model is part of the FR-E700 SERIES and is widely used in industrial automation applications requiring stable speed regulation, reliable torque handling, and efficient induction motor operation.
This Variable Frequency Drive is suitable for conveyors, small machinery, packaging units, blowers, and automated assembly systems. Its STO functionality, LED status display, RS-485 interface, and flexible I/O configuration support dependable operation, consistent speed control, and durable performance in continuous-duty environments.
The Mitsubishi FR-E740-170SC-EC Variable Frequency Drive combines 7.5kW rating, 17A output, vector-based control, and STO safety to support reliable and efficient motor operation. With Mitsubishi’s trusted engineering and the FR-E700 SERIES platform, this model offers stable performance suited for users requiring precise and consistent control of 3-phase induction motors.
