Mitsubishi FR-E720-3.7K-E3 Variable Frequency Drive
Technical Specifications of Mitsubishi Variable Frequency Drive FR-E720-3.7K-E3:
| Brand | Mitsubishi |
| Product Type | Variable Frequency Drive |
| Product | FR-E720-3.7K-E3 |
Mitsubishi Variable Frequency Drive FR-E720-3.7K-E3 Technical Specifications:
| Specification | Value |
|---|---|
| Series | FR-E700 SERIES |
| Type | FR-E700 STANDARD INVERTER |
| Minimum Rated Voltage (V) | 200 |
| Min. Permissible Voltage (V) | 170 |
| Maximum Rated Voltage (V) | 240 |
| Max. Permissible Voltage (V) | 264 |
| Current Type | AC |
| Phases | 3 |
| Rated Output Current ND (A) | 17,5 |
| Rated Motor Capacity ND (kW) | 3,7 |
| Control Method | MAGNETIC FLUX VECTOR CONTROL, V/F CONTROL |
| Motor Type | INDUCTION MOTOR |
| Brake Chopper ED (%) | 30 |
| Integrated EMC Filter | NO |
| Safe Torque Off (STO) | YES |
| Regenerative (4Q) | NO |
| Integrated DC Choke | NO |
| Display | BUILT-IN |
| Display Type | 4 DIGITS LED |
| PLC Function | NO |
| Integrated Digital Inputs | 6 |
| Digital Outputs (Transistor) | 2 |
| Digital Outputs (Relay) | 1 |
| Integrated Analogue Inputs | 2 |
| Integrated Analogue Outputs | 1 |
| IO Type of Terminal Block | SCREW |
| Expandable | YES |
| RS-485 | 1 |
| USB | 1 |
| Built-In Network | MODBUS-RTU |
| Leakage Current (mA) | 1 |
| Power Loss ND (W) | 160 |
| Protection Class | IP20 |
| Depth (mm) | 142,5 |
| Weight (kg) | 1,7 |
| Width (mm) | 170 |
| Height (mm) | 128 |
| Standby Power Consumption (W) | 6,4 |
The FR-E720-3.7K-E3 from Mitsubishiβs FR-E700 series is a high-performance Mitsubishi Variable Frequency Drive (VFD) designed to deliver efficient motor control, energy savings, and long-term reliability. It is suitable for engineers, OEMs, and industries seeking stable and precise automation solutions.
The FR-E720-3.7K-E3 operates on a three-phase 200β240V AC supply and provides a rated motor capacity of 3.7 kW at 17.5A output current. With advanced Magnetic Flux Vector Control and V/F control, this compact drive ensures accurate torque regulation and smooth speed variation for induction motors. Safety is reinforced with a built-in Safe Torque Off (STO) function, while IP20 protection enhances durability in industrial environments. The drive integrates flexible connectivity options such as RS-485 and MODBUS-RTU, along with multiple digital and analog I/O for easy system integration. Its LED display, low standby power consumption, and compact form factor (170 Γ 128 Γ 142.5 mm, 1.7 kg) make it practical for control panels with limited space. Designed with Mitsubishiβs engineering quality, the FR-E700 standard inverter series has been trusted worldwide for reliability and performance in tough conditions.
Applications of the FR-E720-3.7K-E3 span across conveyors, pumps, HVAC systems, mixers, and machine tools where precise motor speed control, reduced downtime, and energy optimization are crucial. Maintenance teams value its straightforward setup, diagnostic features, and compatibility with automation systems. Industries such as packaging, textiles, food processing, and manufacturing benefit from this Mitsubishi Variable Frequency Drive because it delivers stable operation, reduces mechanical stress on motors, and lowers operational costs. By choosing the FR-E720-3.7K-E3, engineers and plant operators ensure long-term performance and compliance with modern safety and efficiency standards.
For procurement and design teams, Mitsubishi provides official resources including the FR-E720-3.7K-E3 manual, FR-E720-3.7K-E3 datasheet, and authorized distributor channels to check the FR-E720-3.7K-E3 price. These resources give engineers access to wiring diagrams, configuration details, and troubleshooting guidance. To maximize performance in automation projects, Mitsubishi recommends sourcing the FR-E720-3.7K-E3 directly from certified vendors for warranty coverage and genuine quality assurance.
