Mitsubishi FR-F840-00310-E2-60 Variable Frequency Drive
The Mitsubishi FR-F840-00310-E2-60 Variable Frequency Drive operates with 380–500V AC 3-phase input, delivering 15kW motor capacity, 29A rated output current, and IP20 protection. It belongs to the Mitsubishi Variable Frequency Drive family under the Mitsubishi brand and forms part of the FR-F800 SERIES. The drive supports V/F and PM Sensorless Vector Control, features a 5-digit LED display, and integrates Safe Torque Off (STO) for secure and efficient motor operation.
| Brand | Mitsubishi |
| Product Type | VFD - Variable Frequency Drive |
| Product | FR-F840-00310-E2-60 |
Mitsubishi Variable Frequency Drive FR-F840-00310-E2-60 Technical Specifications:
| Specification | Value |
|---|---|
| Series | FR-F800 SERIES |
| Type | FR-F800-E INVERTER |
| Minimum Rated Voltage (V) | 380 |
| Min. Permissible Voltage (V) | 323 |
| Maximum Rated Voltage (V) | 500 |
| Max. Permissible Voltage (V) | 550 |
| Current Type | AC |
| Phases | 3 |
| Frequency Range (Hz) | 0,2–590 |
| Control Method | V/F CONTROL, SOFT-PWM/HIGH FREQUENCY PWM, PM SENSORLESS VECTOR CONTROL, MAGNETIC FLUX VECTOR CONTROL |
| Motor Type | INDUCTION MOTOR, PM MOTOR |
| Integrated EMC Filter | YES |
| Safe Torque Off (STO) | YES |
| Regenerative (4Q) | NO |
| Integrated DC Choke | NO |
| Display | FR-DU08 |
| Display Type | 5 DIGITS LED (12 SEGMENT) |
| PLC Function | YES |
| Program Memory | 6K |
| Program Memory Unit | STEPS |
| Integrated Digital Inputs | 12 |
| Digital Outputs (Transistor) | 5 |
| Digital Outputs (Relay) | 2 |
| Integrated Analogue Inputs | 3 |
| Integrated Analogue Outputs | 2 |
| IO Type of Terminal Block | SPRING CLAMP |
| Expandable | YES |
| USB | 1+1 MINI |
| Ethernet Port | 1 |
| Built-In Network | CC-LINK IE FIELD NETWORK BASIC, MELSOFT/FA, iQSS, MODBUS/TCP, SLMP, BACNET/IP |
| Leakage Current (mA) | 35(DELTA) / 2(STAR) |
| Protection Class | IP20 |
| Depth (mm) | 190 |
| Weight (kg) | 8,3 |
| Width (mm) | 220 |
| Height (mm) | 300 |
| Standby Power Consumption (W) | 20 |
| Rated Output Current LD (A) | 29 |
| Rated Motor Capacity LD (kW) | 15 |
| Power Loss LD (W) | 345 |
| Rated Output Current SLD (A) | 31 |
| Rated Motor Capacity SLD (kW) | 15 |
| Power Loss SLD (W) | 370 |
| Shipping Approvals | DNV,ABS |
The Mitsubishi FR-F840-00310-E2-60 Variable Frequency Drive, part of the FR-F800 SERIES, is engineered for reliable performance in industrial automation. With a 15kW power rating, 380–500V AC 3-phase input, and V/F and Sensorless Vector Control, it ensures precise speed control and high efficiency. This Mitsubishi Variable Frequency Drive also features Safe Torque Off (STO) and a 5-digit LED interface for clear operational visibility.
The Mitsubishi FR-F840-00310-E2-60 is ideal for industrial applications such as pumps, fans, conveyors, and HVAC systems. It supports multiple communication protocols, including CC-Link IE Field Network and Modbus/TCP, ensuring smooth integration into automation systems. Its compact IP20 design and energy-efficient vector control make it suitable for continuous-duty environments requiring reliable motor performance.
The Mitsubishi FR-F840-00310-E2-60 Variable Frequency Drive delivers dependable 15kW motor control with excellent stability and safety. As part of Mitsubishi’s trusted FR-F800 SERIES, it reflects the brand’s commitment to precision, durability, and efficiency in industrial automation. Its robust design and control flexibility make it a preferred choice for engineers seeking long-term reliability in India’s industrial sectors.
