Mitsubishi Variable Frequency Drive FR-AF840-04810-60 Technical Specifications:
Specification
Value
Series
FR-A/F800 SERIES
Type
BASE UNIT FOR INV A840/F840
Minimum Rated Voltage (V)
380
Min. Permissible Voltage (V)
323
Maximum Rated Voltage (V)
500
Max. Permissible Voltage (V)
550
Current Type
AC
Phases
3
Rated Output Current ND (A)
361
Rated Motor Capacity ND (kW)
185
Control Method
VECTOR CONTROL
Motor Type
INDUCTION MOTOR, PM MOTOR
Integrated EMC Filter
YES
Safe Torque Off (STO)
YES
Regenerative (4Q)
NO
Integrated DC Choke
NO
Display
FR-DU08
Display Type
5 DIGITS LED
PLC Function
YES
Program Memory
6K
Program Memory Unit
STEPS
Integrated Digital Inputs
12
Digital Outputs (Transistor)
5
Digital Outputs (Relay)
2
Integrated Analogue Inputs
3
Integrated Analogue Outputs
2
IO Type of Terminal Block
SPRING CLAMP
Expandable
YES
RS-485
2
USB
2
Leakage Current (mA)
35(DELTA) / 2(STAR)
Power Loss ND (W)
3850
Protection Class
IP00
Depth (mm)
380
Weight (kg)
117
Width (mm)
498
Height (mm)
1010
Standby Power Consumption (W)
96
Power Loss LD (W)
4650
Power Loss SLD (W)
5300
Rated Motor Capacity HD (kW)
160
Power Loss HD (W)
3400
Get A Quote for Variable Frequency Drive FR-AF840-04810-60 at the best price. Here are the brief Technical Specifications of FR-AF840-04810-60 are BASE UNIT FOR INV A840/F840 from the FR-A/F800 SERIES at competitive prices. This AC inverter operates on 3-phase power with a minimum rated voltage of 380V, a minimum permissible voltage of 323V, a maximum rated voltage of 500V, and a maximum permissible voltage of 550V. It is designed with an IP00 protection class, ensuring safe operation in controlled environments. The inverter has a compact build, with a depth of 380 mm, a width of 498 mm, and a height of 1010 mm, making it suitable for space-constrained installations. It weighs 117 kg, ensuring easy handling and installation. It's Time to get a Quote for your requirement of Variable Frequency Drive. We guarantee unmatched pricing and unparalleled support compared to other Distributors.
