Mitsubishi FR-D720-5.5K Variable Frequency Drive
The Mitsubishi FR-D720-5.5K Variable Frequency Drive offers 5.5kW motor capacity with a 23.8A rated output current for automation systems. This Mitsubishi drive belongs to the Mitsubishi Variable Frequency Drive family and supports V/F control, magnetic flux vector control, and high-frequency PWM for induction motors. As part of the FR-D700 SERIES, the FR-D720-5.5K includes STO safety, IP20 protection, LED display, digital and analogue I/O, RS-485 communication, and MODBUS-RTU capability.
| Brand | Mitsubishi |
| Product Type | VFD - Variable Frequency Drive |
| Product | FR-D720-5.5K |
Mitsubishi Variable Frequency Drive FR-D720-5.5K Technical Specifications:
| Specification | Value |
|---|---|
| Series | FR-D700 SERIES |
| Type | FR-D700 COMPACT INVERTER |
| Minimum Rated Voltage (V) | 200 |
| Min. Permissible Voltage (V) | 170 |
| Maximum Rated Voltage (V) | 240 |
| Max. Permissible Voltage (V) | 264 |
| Current Type | AC |
| Phases | 3 |
| Rated Output Current ND (A) | 23,8 |
| Rated Motor Capacity ND (kW) | 5,5 |
| Control Method | V/F CONTROL, SOFT-PWM/HIGH FREQUENCY PWM , MAGNETIC FLUX VECTOR CONTROL |
| Motor Type | INDUCTION MOTOR |
| Brake Chopper ED (%) | 30 |
| Integrated EMC Filter | NO |
| Safe Torque Off (STO) | YES |
| Regenerative (4Q) | NO |
| Integrated DC Choke | NO |
| Display | BUILT-IN |
| Display Type | 4 DIGITS LED |
| PLC Function | NO |
| Integrated Digital Inputs | 5 |
| Digital Outputs (Transistor) | 1 |
| Digital Outputs (Relay) | 1 |
| Integrated Analogue Inputs | 2 |
| Integrated Analogue Outputs | 1 |
| IO Type of Terminal Block | SPRING CLAMP |
| Expandable | NO |
| RS-485 | 1 |
| USB | NO |
| Ethernet Port | NO |
| Built-In Network | MODBUS-RTU |
| Leakage Current (mA) | 1 |
| Power Loss ND (W) | 270 |
| Protection Class | IP20 |
| Depth (mm) | 155 |
| Weight (kg) | 3,6 |
| Width (mm) | 220 |
| Height (mm) | 150 |
| Standby Power Consumption (W) | 13-22,5 |
The Mitsubishi FR-D720-5.5K Variable Frequency Drive provides 23.8A output, 5.5kW capacity, V/F control, and magnetic flux vector control. This Mitsubishi FR-D720-5.5K unit is part of the FR-D700 SERIES and is used across industrial automation systems requiring precise induction motor control, consistent torque delivery, and reliable speed regulation.
This Variable Frequency Drive suits conveyors, packaging systems, feeders, compact machinery, and light-duty processing applications. Its STO functionality, LED display, RS-485 interface, analogue inputs, and durable construction support smooth performance, stable operation, and efficient motor handling across continuous-duty environments where dependable control is essential.
The Mitsubishi FR-D720-5.5K Variable Frequency Drive combines 5.5kW rating, 23.8A output, vector-based motor control, and STO protection to ensure steady, reliable performance. Backed by Mitsubishi engineering and the FR-D700 SERIES architecture, this model is well suited for users needing safe, consistent, and long-lasting motor control in industrial automation applications.
