Mitsubishi FR-D720-1.5K Variable Frequency Drive
The Mitsubishi FR-D720-1.5K Variable Frequency Drive provides 1.5kW motor capacity with a 7A rated output current for reliable control. This Mitsubishi drive is part of the Mitsubishi Variable Frequency Drive range and supports V/F control, magnetic flux vector control, and soft-PWM modes for induction motors. As a member of the FR-D700 SERIES, the FR-D720-1.5K includes STO protection, IP20 housing, LED display, digital and analogue inputs, RS-485 communication, and MODBUS-RTU compatibility.
| Brand/Manufacturer | Mitsubishi Electric |
| Product Type | VFD (Variable Frequency Drive) |
| Model No. | FR-D720-1.5K |
Mitsubishi Variable Frequency Drive FR-D720-1.5K Technical Specifications:
| Specification | Value |
|---|---|
| Series | FR-D700 SERIES |
| Type | FR-D700 COMPACT INVERTER |
| Minimum Rated Voltage (V) | 200 |
| Min. Permissible Voltage (V) | 170 |
| Maximum Rated Voltage (V) | 240 |
| Max. Permissible Voltage (V) | 264 |
| Current Type | AC |
| Phases | 3 |
| Rated Output Current ND (A) | 7 |
| Rated Motor Capacity ND (kW) | 1,5 |
| Control Method | V/F CONTROL, SOFT-PWM/HIGH FREQUENCY PWM , MAGNETIC FLUX VECTOR CONTROL |
| Motor Type | INDUCTION MOTOR |
| Brake Chopper ED (%) | 30 |
| Integrated EMC Filter | NO |
| Display | BUILT-IN |
| Display Type | 4 DIGITS LED |
| Integrated Digital Inputs | 5 |
| Digital Outputs (Transistor) | 1 |
| Digital Outputs (Relay) | 1 |
| Depth (mm) | 135,5 |
| Width (mm) | 108 |
| Height (mm) | 128 |
| Protection Class | IP20 |
| Weight (kg) | 1,4 |
The Mitsubishi FR-D720-1.5K Variable Frequency Drive offers 1.5kW output capacity, a 7A current rating, vector control capability, and STO safety protection. The Mitsubishi FR-D720-1.5K belongs to the FR-D700 SERIES and is used in industrial automation environments that require dependable speed regulation and compact installation.
This drive is suitable for conveyors, small packaging systems, feeders, mixers, and light-duty automation lines. Its stable control features, MODBUS-RTU support, efficient speed handling, and durable I/O structure make it effective for continuous operation where consistency and reliability are essential.
The Mitsubishi FR-D720-1.5K Variable Frequency Drive combines 1.5kW performance, vector-based control, STO functionality, and RS-485 connectivity to deliver stable control for small industrial motors. Backed by the FR-D700 SERIES, it remains a trusted option for compact installations requiring long-term operational stability and dependable drive performance.
