Mitsubishi FR-A840-00310-E2-60 Variable Frequency Drive
Technical Specifications of Mitsubishi Variable Frequency Drive FR-A840-00310-E2-60:
| Brand | Mitsubishi |
| Product Type | Variable Frequency Drive |
| Product | FR-A840-00310-E2-60 |
Mitsubishi Variable Frequency Drive FR-A840-00310-E2-60 Technical Specifications:
| Specification | Value |
|---|---|
| Series | FR-A SERIES |
| Type | FR-A800-E INVERTER |
| Minimum Rated Voltage (V) | 380 |
| Min. Permissible Voltage (V) | 323 |
| Maximum Rated Voltage (V) | 500 |
| Max. Permissible Voltage (V) | 550 |
| Current Type | AC |
| Phases | 3 |
| Rated Output Current ND (A) | 23 |
| Rated Motor Capacity ND (kW) | 11 |
| Frequency Range (Hz) | 0,2β590 |
| Control Method | VECTOR CONTROL (WITH FR-A8AP), V/F CONTROL, SOFT-PWM/HIGH FREQUENCY PWM, REAL SENSORLESS VECTOR CONTROL, PM SENSORLESS VECTOR CONTROL, MAGNETIC FLUX VECTOR CONTROL |
| Motor Type | INDUCTION MOTOR, PM MOTOR |
| Brake Chopper ED (%) | 100 |
| Integrated EMC Filter | YES |
| Safe Torque Off (STO) | YES |
| Regenerative (4Q) | NO |
| Integrated DC Choke | NO |
| Display | FR-DU08 |
| Display Type | 5 DIGITS LED (12 SEGMENT) |
| PLC Function | YES |
| Program Memory | 6K |
| Program Memory Unit | STEPS |
| Integrated Digital Inputs | 12 |
| Digital Outputs (Transistor) | 5 |
| Digital Outputs (Relay) | 2 |
| Integrated Analogue Inputs | 3 |
| Integrated Analogue Outputs | 2 |
| IO Type of Terminal Block | SPRING CLAMP |
| Expandable | YES |
| RS-485 | OPTIONAL |
| USB | 1+1 MINI |
| Ethernet Port | 1 |
| Built-In Network | CC-LINK IE FIELD NETWORK, MODBUS/TCP, CC-LINK IE FIELD NETWORK BASIC |
| Leakage Current (mA) | 35(DELTA) / 2(STAR) |
| Power Loss ND (W) | 280 |
| Protection Class | IP20 |
| Depth (mm) | 190 |
| Weight (kg) | 8,3 |
| Width (mm) | 220 |
| Height (mm) | 300 |
| Standby Power Consumption (W) | 20 |
| Rated Output Current LD (A) | 29 |
| Rated Motor Capacity LD (kW) | 15 |
| Power Loss LD (W) | 345 |
| Rated Output Current SLD (A) | 31 |
| Rated Motor Capacity SLD (kW) | 15 |
| Power Loss SLD (W) | 370 |
| Shipping Approvals | ABS,BV,DNV GL,LR,NK |
| Rated Output Current HD (A) | 17 |
| Rated Motor Capacity HD (kW) | 7,5 |
| Power Loss HD (W) | 210 |
The Mitsubishi FR-A840-00310-E2-60 Variable Frequency Drive is a robust industrial unit designed for precise motor control. This model offers 23 A ND output current, 11 kW ND capacity, and a 0.2β590 Hz frequency range, enabling accurate speed regulation. Belonging to the FR-A SERIES, this Mitsubishi Variable Frequency Drive is commonly used across industrial automation environments where reliable AC motor performance is essential.
The Mitsubishi FR-A840-00310-E2-60 Variable Frequency Drive suits conveyors, packaging lines, processing equipment, HVAC drives, and automated assembly systems. It supports vector control, V/F control, sensorless vector methods, and multiple motor types, allowing stable torque output and consistent motion. Features such as IP20 protection, STO support, EMC filtering, and network interfaces help maintain dependable operation in continuous-duty industrial workflows.
The Mitsubishi FR-A840-00310-E2-60 Variable Frequency Drive combines strong motor handling with clear specification integrity, including reliable torque control, broad frequency adjustability, and multi-network compatibility. Mitsubishi ensures dependable performance for long-term use in industrial automation, supported by the FR-A SERIES architecture. This model provides predictable operation, consistent drive response, and suitability for demanding applications where accuracy and stability matter.
