Mitsubishi FR-A840-00250-E2-60 Variable Frequency Drive
Technical Specifications of Mitsubishi Variable Frequency Drive FR-A840-00250-E2-60:
| Brand | Mitsubishi |
| Product Type | Variable Frequency Drive |
| Product | FR-A840-00250-E2-60 |
Mitsubishi Variable Frequency Drive FR-A840-00250-E2-60 Technical Specifications:
| Specification | Value |
|---|---|
| Series | FR-A SERIES |
| Type | FR-A800-E INVERTER |
| Minimum Rated Voltage (V) | 380 |
| Min. Permissible Voltage (V) | 323 |
| Maximum Rated Voltage (V) | 500 |
| Max. Permissible Voltage (V) | 550 |
| Current Type | AC |
| Phases | 3 |
| Rated Output Current ND (A) | 17 |
| Rated Motor Capacity ND (kW) | 7,5 |
| Frequency Range (Hz) | 0,2–590 |
| Control Method | VECTOR CONTROL (WITH FR-A8AP), V/F CONTROL, SOFT-PWM/HIGH FREQUENCY PWM, REAL SENSORLESS VECTOR CONTROL, PM SENSORLESS VECTOR CONTROL, MAGNETIC FLUX VECTOR CONTROL |
| Motor Type | INDUCTION MOTOR, PM MOTOR |
| Brake Chopper ED (%) | 100 |
| Integrated EMC Filter | YES |
| Safe Torque Off (STO) | YES |
| Regenerative (4Q) | NO |
| Integrated DC Choke | NO |
| Display | FR-DU08 |
| Display Type | 5 DIGITS LED (12 SEGMENT) |
| PLC Function | YES |
| Program Memory | 6K |
| Program Memory Unit | STEPS |
| Integrated Digital Inputs | 12 |
| Digital Outputs (Transistor) | 5 |
| Digital Outputs (Relay) | 2 |
| Integrated Analogue Inputs | 3 |
| Integrated Analogue Outputs | 2 |
| IO Type of Terminal Block | SPRING CLAMP |
| Expandable | YES |
| RS-485 | OPTIONAL |
| USB | 1+1 MINI |
| Ethernet Port | 1 |
| Built-In Network | CC-LINK IE FIELD NETWORK, MODBUS/TCP, CC-LINK IE FIELD NETWORK BASIC |
| Leakage Current (mA) | 35(DELTA) / 2(STAR) |
| Power Loss ND (W) | 220 |
| Protection Class | IP20 |
| Depth (mm) | 170 |
| Weight (kg) | 6,7 |
| Width (mm) | 220 |
| Height (mm) | 260 |
| Standby Power Consumption (W) | 20 |
| Rated Output Current LD (A) | 23 |
| Rated Motor Capacity LD (kW) | 11 |
| Power Loss LD (W) | 315 |
| Rated Output Current SLD (A) | 25 |
| Rated Motor Capacity SLD (kW) | 11 |
| Power Loss SLD (W) | 345 |
| Shipping Approvals | ABS,BV,DNV GL,LR,NK |
| Rated Output Current HD (A) | 12 |
| Rated Motor Capacity HD (kW) | 5,5 |
| Power Loss HD (W) | 165 |
The Mitsubishi FR-A840-00250-E2-60 Variable Frequency Drive is a high-performance model from the FR-A SERIES, designed for efficient motor speed and torque control in industrial automation. With a 7.5kW rated output, 380–500V AC 3-phase input, and 17A output current, it ensures reliable control of both induction and PM motors. This Mitsubishi Variable Frequency Drive supports Vector Control, V/F Control, and includes built-in STO safety for dependable industrial use.
The Mitsubishi FR-A840-00250-E2-60 is used in applications like conveyors, pumps, compressors, and automated production lines. Its Ethernet networking and PLC function enable seamless integration with control systems, while Soft-PWM technology minimizes noise and enhances operational stability. This makes it ideal for energy-efficient automation environments requiring consistent and precise motor control.
The Mitsubishi FR-A840-00250-E2-60 Variable Frequency Drive delivers dependable performance, durability, and safety within the FR-A SERIES. With its 7.5kW power rating, Vector Control capability, and Safe Torque Off (STO) feature, it provides the reliability expected from the Mitsubishi brand. Trusted in industrial setups across India, this drive ensures smooth, efficient, and safe operation in demanding motor control applications.
