Mitsubishi Variable Frequency Drive FR-A820-01540-E1-60 Technical Specifications:
Specification
Value
Series
FR-A SERIES
Type
FR-A800-E INVERTER
Minimum Rated Voltage (V)
200
Min. Permissible Voltage (V)
170
Maximum Rated Voltage (V)
240
Max. Permissible Voltage (V)
264
Current Type
AC
Phases
3
Rated Output Current ND (A)
115
Rated Motor Capacity ND (kW)
30
Frequency Range (Hz)
0,2β590
Control Method
VECTOR CONTROL (WITH FR-A8AP), V/F CONTROL, SOFT-PWM/HIGH FREQUENCY PWM, REAL SENSORLESS VECTOR CONTROL, PM SENSORLESS VECTOR CONTROL, MAGNETIC FLUX VECTOR CONTROL
Motor Type
INDUCTION MOTOR, PM MOTOR
Integrated EMC Filter
YES (OFF ON INITIAL SETTINGS)
Safe Torque Off (STO)
YES
Regenerative (4Q)
NO
Integrated DC Choke
NO
Display
FR-DU08
Display Type
5 DIGITS LED (12 SEGMENT)
PLC Function
YES
Program Memory
6K
Program Memory Unit
STEPS
Integrated Digital Inputs
12
Digital Outputs (Transistor)
5
Digital Outputs (Relay)
2
Integrated Analogue Inputs
3
Integrated Analogue Outputs
2
IO Type of Terminal Block
SPRING CLAMP
Expandable
YES
USB
1+1 MINI
Ethernet Port
1
Built-In Network
CC-LINK IE FIELD NETWORK, CC-LINK IE FIELD NETWORK BASIC, MODBUS/TCP
Leakage Current (mA)
22
Power Loss ND (W)
1050
Protection Class
IP00
Depth (mm)
195
Weight (kg)
22
Width (mm)
325
Height (mm)
550
Rated Output Current LD (A)
140
Rated Motor Capacity LD (kW)
37
Power Loss LD (W)
1300
Rated Output Current SLD (A)
154
Rated Motor Capacity SLD (kW)
37
Power Loss SLD (W)
1450
Rated Output Current HD (A)
90
Rated Motor Capacity HD (kW)
22
Power Loss HD (W)
880
Call us for Variable Frequency Drive FR-A820-01540-E1-60 at the best rates. Technical Attributes of FR-A820-01540-E1-60 are FR-A800-E INVERTER from the FR-A SERIES at competitive prices. This AC inverter operates on 3-phase power with a minimum rated voltage of 200V, a minimum permissible voltage of 170V, a maximum rated voltage of 240V, and a maximum permissible voltage of 264V. It is designed with an IP00 protection class, ensuring safe operation in controlled environments. The inverter has a compact build, with a depth of 195 mm, a width of 325 mm, and a height of 550 mm, making it suitable for space-constrained installations. It weighs 22 kg, ensuring easy handling and installation. Unlock Exclusive Pricing with a Quote for your requirement of Variable Frequency Drive. Trust in our ability to provide more advantageous pricing and dedicated support beyond other other Dealers.
