Mitsubishi Variable Frequency Drive FR-A741-22K Technical Specifications:
Specification
Value
Series
FR-A SERIES
Type
FR-A741 INVERTER
Minimum Rated Voltage (V)
380
Min. Permissible Voltage (V)
323
Maximum Rated Voltage (V)
480
Max. Permissible Voltage (V)
528
Current Type
AC
Phases
3
Rated Output Current ND (A)
44
Rated Motor Capacity ND (kW)
22
Frequency Range (Hz)
0,2β400
Control Method
VECTOR CONTROL
Motor Type
INDUCTION MOTOR
Brake Chopper ED (%)
30
Integrated EMC Filter
YES
Safe Torque Off (STO)
NO
Regenerative (4Q)
YES
Integrated DC Choke
NO
Display
FR-DU07
Display Type
4 DIGITS LED
PLC Function
YES
Program Memory
1K
Program Memory Unit
STEPS
Integrated Digital Inputs
12
Digital Outputs (Transistor)
5
Digital Outputs (Relay)
2
Integrated Analogue Inputs
3
Integrated Analogue Outputs
2
IO Type of Terminal Block
SCREW
Expandable
YES
RS-485
2
USB
1
Built-In Network
MODBUS-RTU
Leakage Current (mA)
1
Power Loss ND (W)
1290
Protection Class
IP00
Depth (mm)
320
Weight (kg)
49
Width (mm)
360
Height (mm)
600
IndMALL Automation Dealing offers Variable Frequency Drive FR-A741-22K at unbeatable prices. The Main Technical Parameters of FR-A741-22K are FR-A741 INVERTER from the FR-A SERIES at competitive prices. This AC inverter operates on 3-phase power with a minimum rated voltage of 380V, a minimum permissible voltage of 323V, a maximum rated voltage of 480V, and a maximum permissible voltage of 528V. It is designed with an IP00 protection class, ensuring safe operation in controlled environments. The inverter has a compact build, with a depth of 320 mm, a width of 360 mm, and a height of 600 mm, making it suitable for space-constrained installations. It weighs 49 kg, ensuring easy handling and installation. Take the First Step with a Quote for your requirement of Variable Frequency Drive. Choose us for unparalleled pricing and support over other Dealers & Distributors.
