Procurement managers rarely finalize LS25C-XX-M8 without reviewing Sick Diffuse Sensor, Leuze Ls5B Xx 200 M12 and Leuze Proximity Sensor, ensuring that the chosen component meets budget, compliance, and delivery conditions.
Leuze LS25C/XX-M8 Photoelectric Sensor
The Leuze LS25C/XX-M8 Photoelectric Sensor (Part No: 50146028 ) offers a Throughbeam principle, 0... 30 m operating range, M8 Connector 4-pin . Manufactured by Leuze under the Leuze Photoelectric Sensor category, this model belongs to the LS 5 Series.
| Brand | Leuze |
| Product Type | Photoelectric Sensor |
| Product | LS25C/XX-M8 |
Leuze LS25C/XX-M8 Photoelectric Sensor β Technical Specifications
| Specification | Value |
|---|---|
| Series | LS 25 Series |
| Operating principle | Throughbeam principle |
| Device type | Transmitter |
| Operating range | 0... 30 m |
| Light source | LED, Red |
| Wavelength | - |
| Power Supply | 10 ... 30 V, DC |
| Open-circuit current | 0 ... 20 mA |
| Readiness delay | 300 ms |
| Connection Function | Voltage supply |
| Type of Connection | M8 Connector |
| Number of conductors or Pins | 4-pin |
| Dimension | 15 mm x 42.7 mm x 30 mm |
| Housing material | Plastic: ABS |
| Lens cover material | Plastic |
| Housing color | Red |
| Type of display | LED |
| Ambient temperature | Operation: -40 ... 60 Β°C Storage: -40 ... 70 Β°C |
| Degree of protection | IP 67, IP 69K |
| Net weight | 22 g |
Mail us for Leuze PUR M8 Connector Transmitter Sensor LS25C/XX-M8 part no: 50146028 with budget-friendly prices. Technical Details of LS25C/XX-M8, 50146028 are 25C series, Throughbeam, Transmitter device, 0... 30 m operating range, LED, Red light source, 10 ... 30 V, DC power supply, 0 ... 20 mA current, M8 Connector, 4-pin, PUR material, 15 mm x 42.7 mm x 30 mm dimensions, Red housing color, LED display, IP 67, IP 69K degree of protection. Elevate Your Project with a Quote for your requirement of Leuze PUR M8 Connector Transmitter Sensor. Rest assured, our pricing and support outshine other Suppliers.
