Leuze LS25CI.XXR/XX-M12 Photoelectric Sensor
The Leuze LS25CI.XXR/XX-M12 Photoelectric Sensor (Part No: 50147912 ) offers a Throughbeam principle, 0... 400 m operating range, M12 Connector 4-pin . Manufactured by Leuze under the Leuze Photoelectric Sensor category, this model belongs to the LS 5 Series.
| Brand | Leuze |
| Product Type | Photoelectric Sensor |
| Product | LS25CI.XXR/XX-M12 |
Leuze LS25CI.XXR/XX-M12 Photoelectric Sensor – Technical Specifications
| Specification | Value |
|---|---|
| Series | LS 25 Series |
| Operating principle | Throughbeam principle |
| Device type | Transmitter |
| Operating range | 0... 400 m |
| Light source | LED, Infrared |
| Wavelength | 860 nm |
| Power Supply | 10 ... 30 V, DC |
| Open-circuit current | 0 ... 20 mA |
| Readiness delay | 300 ms |
| Connection Function | Signal IN Voltage supply |
| Type of Connection | M12 Connector |
| Number of conductors or Pins | 4-pin |
| Dimension | 15 mm x 42.7 mm x 30 mm |
| Housing material | Plastic: ABS |
| Lens cover material | Plastic |
| Housing color | Red |
| Type of display | LED |
| Ambient temperature | Operation: -40 ... 60 °C Storage: -40 ... 70 °C |
| Degree of protection | IP 67, IP 69K |
| Net weight | 22 g |
Send Your Inquiry for Leuze PUR 4-pin Transmitter Sensor LS25CI.XXR/XX-M12 part no: 50147912 at affordable rates. Core System Specifications of LS25CI.XXR/XX-M12, 50147912 are 25C series, Throughbeam, Transmitter device, 0... 400 m operating range, LED, Infrared light source, 860 nm wavelength, 10 ... 30 V, DC power supply, 0 ... 20 mA current, M12 Connector, 4-pin, 15 mm x 42.7 mm x 30 mm dimensions, Red housing color, LED display, IP 67, IP 69K degree of protection. Initiate Your Journey with a Quote for your requirement of Leuze PUR 4-pin Transmitter Sensor. Trust in our ability to provide more advantageous pricing and dedicated support beyond other Suppliers & Traders.
