Leuze LS22 Photoelectric Sensor
The Leuze LS22 Photoelectric Sensor (Part No: 50140838 ) offers a Throughbeam principle, 0 ... 1 m operating range, PVC Cable, 2m Length 2-wire . Manufactured by Leuze under the Leuze Photoelectric Sensor category, this model belongs to the LS 5 Series.
| Brand | Leuze |
| Product Type | Photoelectric Sensor |
| Product | LS22 |
Leuze LS22 Photoelectric Sensor β Technical Specifications
| Specification | Value |
|---|---|
| Series | LS 22 Series |
| Operating principle | Throughbeam principle |
| Device type | Transmitter |
| Operating range | 0 ... 1 m |
| Light source | LED, Red |
| Wavelength | 630 nm |
| Power Supply | 11 ... 26 V, DC |
| Open-circuit current | - |
| Readiness delay | 100 ms |
| Connection Function | Voltage supply |
| Type of Connection | PVC Cable, 2m Length |
| Number of conductors or Pins | 2-wire |
| Dimension | 16.2 mm x 30 mm x 6.8 mm |
| Housing material | Plastic: PC-PBT |
| Lens cover material | Plastic |
| Housing color | Black |
| Type of display | LED |
| Ambient temperature | Operation: -25 ... 55 Β°C Storage: -25 ... 75 Β°C |
| Degree of protection | IP 67 |
| Net weight | - |
IndMALL Dealling Leuze 1 m Operating Range Transmitter Sensor LS22 part no: 50140838 with the special pricing. Technical Specs Summary of LS22, 50140838 feature 22 series, Throughbeam, Transmitter device, 0 ... 1 m operating range, LED, Red light source, 630 nm wavelength, 11 ... 26 V, DC power supply, - current, PVC Cable, 2m Length, 2-wire, 16.2 mm x 30 mm x 6.8 mm dimensions, Black housing color, LED display, IP 67 degree of protection. Match Your Needs with a Quote for your requirement of Leuze 1 m Operating Range Transmitter Sensor. Our pricing and support are unrivaled, especially when compared to other Distributors.
